Ordering Information; Bill Of Materials; Related Links - Analog Devices EVAL-ADM3051EBZ User Manual

UG-330

ORDERING INFORMATION

BILL OF MATERIALS

Table 1.
Quantity Reference Designator
1 C1
1 C2
1 C3
1 C4
1 CANH, TXD, VREF
3 CANL, RS, RXD
2 GND
1 J1, J3
1 J4
1 R1, R2
1 R3
2 RS1
1 U1

RELATED LINKS

Resource
ADM3051
Description
Tantalum capacitor, 22 µF, TAJ_C
Capacitor, 100 nF, 0603
Capacitor, 47 nF, 0805
DNI
Test point
Test point
Test point
Connector\POWER
Connector\POWER4
Resistor, 30 Ω, 0805
Resistor, 0 Ω, 0805
Resistor, 47 kΩ, 0805
8-lead SOIC
Description
Product Page, High Speed Industrial CAN Transceiver with Bus Protection for 24 V Systems
Rev. 0 | Page 6 of 8
Evaluation Board User Guide
Supplier/Part Number
AVX Corporation/TAJC226K016RNJ
AVX Corporation/06033C104JAT2A
Multicomp/MCCA000270
N/A
Vero Technologies/20-313140
Vero Technologies/20-313138
Vero Technologies/20-2137
Camden Electronics/CTB5000/2
Camden Electronics/CTB5000/4
Multicomp/MCPWR05FTFW0300
Vishay Draloric/CRCW08050000Z0EA
Multicomp/MC 0.1W 0805 5% 47K
Analog Devices/ADM3051CRZ
