ZXR10
Router/Ethernet Switch
Command Manual (Remote Access Volume)
Version 4.8.22
ZTE CORPORATION
ZTE Plaza, Keji Road South,
Hi-Tech Industrial Park,
Nanshan District, Shenzhen,
P. R. China
518057
Tel: (86) 755 26771900
Fax: (86) 755 26770801
URL: http://ensupport.zte.com.cn
E-mail: support@zte.com.cn

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ZXR10 and is the answer not in the manual?

Questions and answers

Related Manuals for Zte ZXR10

Summary of Contents for Zte ZXR10

  • Page 1 ZXR10 Router/Ethernet Switch Command Manual (Remote Access Volume) Version 4.8.22 ZTE CORPORATION ZTE Plaza, Keji Road South, Hi-Tech Industrial Park, Nanshan District, Shenzhen, P. R. China 518057 Tel: (86) 755 26771900 Fax: (86) 755 26770801 URL: http://ensupport.zte.com.cn E-mail: support@zte.com.cn...
  • Page 2 The contents of this document are protected by copyright laws and international treaties. Any reproduction or distribution of this document or any portion of this document, in any form by any means, without the prior written consent of ZTE CORPO- RATION is prohibited.

  • Page 3: Table Of Contents

    About This Manual..........i Command Introduction ........1 Manual Use Guide............1 Description of Man-Machine Commands ......1 Auxiliary Function ............2 Command Mode ............. 3 ATM Protocol Configuration .......7 atm bandwidth ............... 7 atm pvc ................ 8 oam retry ..............8 oam-pvc................
  • Page 4 frame-relay lmi-type ............23 frame-relay map ............24 frame-relay switching.............24 show frame-relay lmi .............25 show frame-relay map ...........25 show frame-relay pvc.............26 X.25 Protocol Configuration ......27 show x.25 default-trunk-config........27 show x.25 forward table ..........28 show x.25 lapb-information ..........28 show x.25 operation ............30 show x.25 packet-information .........31 show x.25 station-information .........34 show x.25 trunk-table ............35...
  • Page 5 backup delay ..............47 backup interface............48 backup load ..............48 chat-script ..............49 dialer group ..............49 dialer hold-queue ............50 dialer idle-timeout ............50 dialer legacy ..............50 dialer list ..............50 dialer load-threshold ............51 dialer map ..............51 dialer modem-script............52 dialer number ...............52 dialer pool ..............52 dialer pool-member ............53 dialer remote-name ............53 dialer spy ..............54 dialer spy enable ............54...

  • Page 7: About This Manual

    Purpose operation of ZXR10 router and Ethernet switch. This manual is intended for engineers and technicians who perform Intended Audience operation activities on ZXR10 router and Ethernet switch. This manual contains the following chapters: What Is in This Manual Chapter...
  • Page 8 ZXR10 Command Manual (Remote Access Volume) � ZXR10 Router/Ethernet Switch Command Manual (MPLS Vol- ume) � ZXR10 Router/Ethernet Switch Command Manual (QoS Vol- ume) � ZXR10 Router/Ethernet Switch Command Manual (Security Volume) � ZXR10 Router/Ethernet Switch Command Manual (Network Management Volume) �...

  • Page 9: Command Introduction

    To search a command, do as follows: 1. Find the desired command by referring to ZXR10 Router/Eth- ernet Switch Command Manual — Command Index. 2. Find command details by the volume, chapter/section and page of the obtained command.

  • Page 10: Auxiliary Function

    Do not describe the history command if this entry does not exist. Auxiliary Function The auxiliary function for ZXR10 devices is as follows. 1. In any command mode, enter a question mark (?) after the DOS prompt of the system, a list of available commands in the command mode will be displayed.

  • Page 11: Command Mode

    ENTER. The ^ is below the first character of the input incorrect command, keyword or parameter. 3. ZXR10 router/Ethernet switch allows the command or key- word to be abbreviated into a character or character string that uniquely identifies this command or keyword. For example, the show command can be abbreviated to sh or sho.
  • Page 12 ZXR10 Command Manual (Remote Access Volume) Mode Prompt Admis- Entry Functions sion Command Mode Inter- ZXR10(config- Global interface Configures face if)# config- port config- uration parameters uration mode and selects mode a port type depending on the keyword Subin- ZXR10 (config-...
  • Page 13 Configures ospf OSPFv3 parameters ZXR10(config- Global ip vrf Configures config- vrf)# config- uration uration parameters mode mode VFI con- Global ZXR10(config- Configures figu- config- vfi)# VPLS related ration uration parameters mode mode Confidential and Proprietary Information of ZTE CORPORATION...
  • Page 14 ZXR10 Command Manual (Remote Access Volume) Mode Prompt Admis- Entry Functions sion Command Mode Route IPv4 ad- ZXR10(config- address-fam Configures config- dress router-af)# ily ipv4 vrf RIP VRF uration family parameters config- mode uration (RIP) mode Route address-fam Configures config-...

  • Page 15: Atm Protocol Configuration

    Bandwidth corresponding to the numbers th> of cells per second, unit: Kbps, range: 150~366794 � It is only applied to ZXR10 GER. Instructions � By default, the interface bandwidth is 2M. This example describes how to configure the bandwidth of Example atm155_1/1.1 to 2M.

  • Page 16: Atm Pvc

    Virtual channel identifiers 0~31 are reserved for the ATM forum Instructions and thus cannot be configured. � It is applied to ZXR10 GER and ZXR10 T64E/T128. This example describes how to create PVC on atm155_1/1.1 with Example the virtual path identifier as 1 and virtual channel identifier as 33.

  • Page 17: Oam-Pvc

    Chapter 2 ATM Protocol Configuration This command is only applied to ZXR10 GER and ZXR10 Instruction T64E/T128. This example describes how to configure PVC retry times. Example ZXR10(config)#interface atm155_1/1.1 ZXR10(config-if)#oam retry 2 2 2 oam-pvc Use this command to enable oamF5 management on PVC. Disable Function the function with the no form of this command.
  • Page 18 The virtual path identifier is in the range of 0~255 <vci> The virtual channel identifier is in the range of 0~65535 It is applied to ZXR10 GER and ZXR10 T64E/T128. Instruction This example describes how to show the configured PVC connec- Example tion and its parameters.

  • Page 19: Ppp Protocol Configuration

    Specifies to configure the public user group special Specifies to configure the private user group <usergroup-name> Name of private user group This command without the parameters specifies the public user Instruction group by default. user-group Related Command Confidential and Proprietary Information of ZTE CORPORATION...

  • Page 20: Multilink-Group

    Syntax Description <multilink-number> Multilink interface number, such as multilink3 It is applied to ZXR10 GAR and ZXR10 ZSR. Instruction This example describes how to bind the link through e1_1/1.1 to Example multilink1 of the specified MPPP interface. ZXR10(config)#interface e1_1/1.1...

  • Page 21: Ppp Authentication Mode

    (refers to the ppp authentication server command for the selection and configuration of Radius server. This example describes how to configure the PPP authentication Example mode on pos48_/1 as local-Radius. ZXR10(config)#interface pos48_1/1 ZXR10(config-if)#ppp authentication mode local-radius Confidential and Proprietary Information of ZTE CORPORATION...

  • Page 22: Ppp Authentication Server

    ZXR10 Command Manual (Remote Access Volume) ppp authentication server Use this command to configure the Radius server for PPP Radius Function authentication. Interface configuration Command Mode ppp authentication server <number> Syntax no ppp authentication server Syntax Description <number> Radius authentication server number, in the range of 1~10 Radius server number 1 is the default setting.

  • Page 23: Ppp Local

    Use this command to set the MPPP EPD attribute. MPPP EPD at- Function tribute distinguishes the link negotiation which belongs to the dif- ferent MPPP sub-links. Cancel the settings with the no form of this command. Confidential and Proprietary Information of ZTE CORPORATION...

  • Page 24: Ppp Open

    The user name and password are not configured by default. Default Both the <user name> and <password>are case sensitive. Instructions This example describes how to configure the username as ZXR10 Example and configure the password as zxr10 on pos48_1/1. Confidential and Proprietary Information of ZTE CORPORATION...

  • Page 25: Ppp Remote

    {negotiation |authentication}[<timeout>] Syntax no ppp timeout {negotiation|authentication} Syntax Description negotiation Link negotiation authentication Link authentication <timeout> Timeout in the range of 1~30 By default, Authentication and Negotiation timeout is 5 seconds. Default Confidential and Proprietary Information of ZTE CORPORATION...

  • Page 26: Show Ppp Multilink

    Configure a relative larger value in the case of link congestion Instructions to avoid frequent authentication/negotiation failure. � This command is available to ZXR10 GAR Version 2.2. This example describes how to configure the negotiation option on Example ce1_1/1.1. ZXR10(config)#interface ce1_1/1.1...

  • Page 27: Frame Relay Protocol

    DLCI value of the interface This command is effective only in Frame-Delay point-to-point Instruction mode This example describes how to set the interface DLCI to 100. Example ZXR10(config-if)#frame-relay interface-dlci 100 frame-relay interface-mode Related Command Confidential and Proprietary Information of ZTE CORPORATION...

  • Page 28: Frame-Relay Interface-Mode

    Sets the point-to-point interface mode point-to-multipoint Sets the point-to-multipoint interface mode � It is only applied to ZXR10GAR, ZXR10 ZSR and ZXR10 GER. Instructions � To configure this command, the interface encapsulation mode has to be configured as FR.

  • Page 29: Frame-Relay Lmi-N391Dte

    Description <keep-exchanges> Full state query interval, in the range of 1~255, 6 is the default value It is only applied to ZXR10 GAR and ZXR10 ZSR. Instruction This example describes how to set the full state query interval as Example...

  • Page 30: Frame-Relay Lmi-N393Dce

    Description <events> Event count, in the range of 1~10, 4 is the default value It is only applied to ZXR10 GAR and ZXR10 ZSR. Instructions This example describes how to set the dce event count as 4. Example ZXR10(config)#interface e1_1/1.1...

  • Page 31: Frame-Relay Lmi-T392Dce

    This value must be larger than the keep-alive timer value of the Default DTE/NNI at the peer end. It is only applied to ZXR10 GAR and ZXR10 ZSR. Instructions This example describes how to set the t392 value of dce as 20.

  • Page 32: Frame-Relay Map

    DLCI value, in the range of 16~1007 <encap> Encapsulation mode, ietf or cisco, default: ietf � It is only applied to ZXR10 GAR and ZXR10 ZSR. Instructions � The IP address should be the IP address of the peer. �...

  • Page 33: Show Frame-Relay Lmi

    Syntax Description interface <interface- Shows the information of the specified name> interface It is only applied to ZXR10 GAR and ZXE10 ZSR. Instructions This example describes how to display lmi information of the FR Example interface. ZXR10#show frame-relay lmi LMI Statistics for interface serial_1/1...

  • Page 34: Show Frame-Relay Pvc

    Displays information about the specified name> interface <dlci> DLCI value in the range of 16~1007 It is only applied for ZXR10 GAR, ZXR10 ZSR. Instruction This example describes how to show the PVC on the FR interface. Example ZXR10#show frame-relay pvc...

  • Page 35: Protocol Configuration

    ..............44 x.25 svc-idletime...............44 x.25 x.121-trunk ...............45 x.25 x.121-user ..............45 x.25 xconnect ..............45 show x.25 default-trunk-con Use this command to display information about the configuration Function of X.25 default relay. Confidential and Proprietary Information of ZTE CORPORATION...

  • Page 36: Show X.25 Forward Table

    ZXR10 Command Manual (Remote Access Volume) All modes except user EXEC Command Mode show x.25 default-trunk-config Syntax This example describes how to display information about the con- Example figuration of X.25 default relay. ZXR10(config)# show x.25 default-trunk-config x.25 default trunk : serial_5/3 The descriptions of above information is displayed as follows.
  • Page 37 Chapter 5 X.25 Protocol Configuration This example describes how to show the X.25 LAPB layer data on Example the serial_5/1. ZXR10(config)# show x.25 lapb-information interface serial_5/1 LapbFlowBusyDefers LapbFlowRejOutPkts LapbFlowRejInPkts LapbFlowT1Timeouts LapbFlowRROutPkts LapbFlowRRInPkts LapbFlowRNROutPkts LapbFlowRNRInPkts LapbFlowIOutPkts LapbFlowIInPkts LapbFlowDMOutPkts LapbFlowDMInPkts LapbFlowSABOutPkts LapbFlowSABInPkts...

  • Page 38: Show X.25 Operation

    ZXR10 Command Manual (Remote Access Volume) Field Description LapbFlowSABInPkts Number of incoming packets of ASB frame of link layer flow LapbFlowUAOutPkts Number of outgoing packets of UA frame of link layer flow LapbFlowUAInPkts Number of incoming packets of UA frame of...

  • Page 39: Show X.25 Packet-Information

    <interface-name> Syntax Syntax Description <interface-name> Interface name This example describes how to display the X.25 packet layer data Example on serial_5/1. ZXR10(config)# show x.25 packet-information interface serial_5/1 Receive CALLREQUEST number Confidential and Proprietary Information of ZTE CORPORATION...
  • Page 40 ZXR10 Command Manual (Remote Access Volume) Receive CALLACCEPTED number Receive CLEARREQUEST number Receive CLEARCONFIRMATION number Receive DATA number Receive INTERRUPT number Receive INTERRUPTCONFIRMATION number Receive RR number Receive RNR number Receive REJ number Receive RESETREQUEST number Receive RESETCONFIRMATION number Receive REGISTRATIONREQUEST number...
  • Page 41 Send INTERRUPTCON- Number of sent interruption confirmation FIRMATION number messages Send RR number Number of sent RR frames Send RNR number Number of sent RNR frames Send REJ number Number of sent REJ frames Confidential and Proprietary Information of ZTE CORPORATION...

  • Page 42: Show X.25 Station-Information

    ZXR10 Command Manual (Remote Access Volume) Field Description Send RESETREQUEST Number of sent reset requests number Send RESETCONFIR- Number of sent reset confirmation messages MATION number Send REGISTRATION- Number of sent registration requests REQUEST number Send REGISTRATION- Number of sent registration configuration...

  • Page 43: Show X.25 Trunk-Table

    This example describes how to display information about the X.25 Example user table. ZXR10(config)# show x.25 user-table interface-name x.121-address serial_5/1 12345 serial_5/2 12321 Descriptions of the displayed information are shown below. Field Description interface-name Interface name x.121-address X.121 address Priority Confidential and Proprietary Information of ZTE CORPORATION...

  • Page 44: Default-Trunk

    ZXR10 Command Manual (Remote Access Volume) x.25 default-trunk Use this command to configure the default X.25 trunk mode. Can- Function cel the setting with the no form of this command. Global configuration Command Mode x.25 default-trunk <interface-name> Syntax no x.25 default-trunk...

  • Page 45: Module

    1032: the maximum frame length is 1032 136: the maximum frame length is 136 264: the maximum frame length is 264 520: the maximum frame length is 520 The default maximum frame length is 136. Default Confidential and Proprietary Information of ZTE CORPORATION...

  • Page 46: Lapb Retransfer Count

    ZXR10 Command Manual (Remote Access Volume) This example describes how to set the X.25 packet layer frame Example length of synchronous serial interface serial_1/1. ZXR10(config)#interface serial_1/1 ZXR10(config-if)# x.25 lapb packet-size 1032 x.25 lapb retransfer count Use this command to set the X.25 retransfer count. Restore de- Function fault with the no form of this command.

  • Page 47: Lapb Timeout T2

    This example describes how to set the X.25 receiving timer T2 to Example 15 seconds on the synchronous serial interface serial_1/1. ZXR10(config)#interface serial_1/1 ZXR10(config-if)# x.25 lapb timeout t2 15 x.25 lapb timeout t3 Use this command to configure the channel idle timer T3. Restore Function default with the no form of this command.

  • Page 48: Packet Length-Size

    ZXR10 Command Manual (Remote Access Volume) Syntax Description <size> X.25 window size, in the range of 2~127 The default X.25 window size is 7. Default This command must refer to the module value. Module 8 ranges Instructions from 2 to 7, and module 128 ranges from 2 to 127.

  • Page 49: Packet Timeout T20

    This example describes how to set the X.25 packet layer maximum Example VC count of synchronous serial interface serial_1/1. ZXR10(config)#interface serial_1/1 ZXR10(config-if)# x.25 packet max-virtual connect 10 x.25 packet timeout t20 Use this command to configure the restart timer T20. Restore Function default with the no form of this command.

  • Page 50: Packet Timeout T22

    ZXR10 Command Manual (Remote Access Volume) x.25 packet timeout t22 Use this command to configure the reset timer T22. Restore de- Function fault with the no form of this command. Interface configuration Command Mode x.25 packet timeout t22 <second> Syntax no x.25 packet timeout t22...

  • Page 51: Port-Manner

    This example describes how to set the X.25 packet layer window Example size of synchronous serial interface serial_1/1. ZXR10(config)#interface serial_1/1 ZXR10(config-if)# x.25 packet window size 10 x.25 port-manner Use this command to configure the X.25 port management mode. Function Restore default with the no form of this command.

  • Page 52: Station

    ZXR10 Command Manual (Remote Access Volume) <interface-name> X.25 end interface number (interface name) <lcn-num> X.25 end LCN, in the range of 1~1024 This example describes how to configure the X.25 PVC. Example ZXR10(config)# x.25 pvc 10 interface serial_5/1 lcn 10 interface serial_5/1 lcn 10 x.25 station...

  • Page 53: X.121-Trunk

    <num> Qos (1~3) This example describes how to configure the X.25 trunk table. Example ZXR10(config)# x.25 x.121-trunk 123 interface serial_5/3 Qos 1 x.25 x.121-user Use this command to configure the X.25 user table. Delete the Function setting with the no form of this command.
  • Page 54 ZXR10 Command Manual (Remote Access Volume) x.25 xconnect ingress <interface id1> egress <interface id2> Syntax dlci <dlci> no x.25 xconnect ingress <interface id1> egress <interface id2> dlci <dlci> Syntax Description X.25 ingress ID <interface id1> FR egress ID <interface id2>...

  • Page 55: Dial-Up Configuration

    Use this command to set the backup link starting time and end Function time. Restore the default configuration with the no form of this command. Interface configuration Command Mode backup delay <enable-time><disable-time> Syntax no backup delay Confidential and Proprietary Information of ZTE CORPORATION...

  • Page 56: Backup Interface

    Waiting time to disable the backup link after the active link is connected again, in seconds, range: 0~65535, 0 by default It is only applied to ZXR10 GAR and ZXR10 ZSR. Instruction This example describes how to configure the starting time and the...

  • Page 57: Chat-Script

    Disables the dial load lower limit of the backup interface either | input | Defines the load control direction output It is only applied to ZXR10 GAR and ZXR10 ZSR. Instruction modem script Related Command chat-script Use this command to configure the script that places a call. Cancel Function the configuration with the no form of this command.

  • Page 58: Dialer Hold-Queue

    Command Mode dialer hold-queue <size> Syntax Syntax Description <size> Queue length It is only applied to ZXR10 GAR and ZXR10 ZSR. Instruction dialer idle-timeout Use this command to define the idle timeout of the dial interface. Function Interface configuration Command Mode dialer idle-timeout <time>...

  • Page 59: Dialer Load-Threshold

    This example describes how to configure DOD trigger data flow. Example The dial list number is 110. ZXR10(config)#dialer-list 100 protocol ip access-list 110 It is only applied to ZXR10 GAR and ZXR10 ZSR. Instruction show dialer list Related Command dialer load-threshold Use this command to enable multi-link load threshold.

  • Page 60: Dialer Modem-Script

    <name-string> Dial-up peer name <script-string> Modem dial-up script <number> Dial-up number It is only applied to ZXR10 GAR and ZXR10 ZSR. Instruction modem script Related Command dialer modem-script Use this command to define the interface dial-up script. Function Interface configuration Command Mode dialer modem-script <script>...

  • Page 61: Dialer Pool-Member

    <pool-number> Syntax no dialer pool Syntax Description <pool-number> Dial-up set number It is only applied to ZXR10 GAR and ZXR10 ZSR. Instruction dialer pool-member Related Commands show dialer pool dialer pool-member Use this command to add the interface to a specified dial-up set.

  • Page 62: Dialer Spy

    Function the dial-up interface. Interface configuration Command Mode dialer spy enable Syntax no dialer spy enable It is only applied to ZXR10 GAR and ZXR10 ZSR. Instruction dialer spy Related Commands show dialer spy dialer spy interval dialer spy group...

  • Page 63: Dialer Spy Interval

    Chapter 6 Dial-up Configuration dialer spy-group <group> Syntax no dialer spy-group Syntax Description <group> Routing listening group number It is only applied to ZXR10 GAR and ZXR10 ZSR. Instruction dialer spy Related Commands show dialer spy dialer spy enable dialer spy interval...

  • Page 64: Modem Script

    Description <script-name> Dial-up script identifier The dial-up script is not set by default. Default It is only applied to ZXR10 GAR and ZXR10 ZSR. Instruction This example describes how to set the serial_2/1 dial-up script as Example 50001. ZXR10(config)#interface serial_2/1...

  • Page 65: Show Dialer Spy

    DOD routing listening group. Privileged configuration Command Mode show dialer spy Syntax It is only applied to ZXR10 GAR and ZXR10 ZSR. Instruction This example describes how to display information about the con- Example figured DOD routing listening group. ZXR10#show dialer spy...
  • Page 66 ZXR10 Command Manual (Remote Access Volume) This page is intentionally blank. Confidential and Proprietary Information of ZTE CORPORATION...

  • Page 67: Tdmoip Configuration

    Enables the CET adaptive function local Disables the CET adaptive function. It is local by default It is only applied to ZXR10 GAR and ZXR10 ZSR. Instruction clock-adaptive {enable| disable} Related Command clock-adaptive Use this command to configure the context clock synchronization Function function.

  • Page 68: Context Slot

    Disables the clock-adaptive function on the context � It is only applied to ZXR10 GAR and ZXR10 ZSR. Instructions � At present, the clock-adaptive function can be enabled on one context only. It is recommended to use number 1 context.

  • Page 69: Ip Dscp

    <destination udp port Configures the UDP destination port number> corresponding to the context It is only applied to ZXR10 GAR and ZXR10 ZSR. Instruction ip dscp Use this command to configure the IP DSCP field of the packet. Function Remove the field with the no form of this command.

  • Page 70: Ip Tos

    Description <tos-value> IP precedence value, in the range of 1~15 � It is only applied to ZXR10 GAR and ZXR10 ZSR. Instructions � This command configures the 4–bit value in the TOS field of the IP packet to represent the TOS.

  • Page 71: Time-Slots Interface

    Syntax Description <length> Maximum length of the frame in the configured context It is only applied to ZXR10 GAR and ZXR10 ZSR. Instruction time-slots interface Use this command to configure the context timeslot. Delete the Function configuration with the no form of this command.
