ZXR10
Router/Ethernet Switch
Command Manual (QoS Volume)
Version 4.8.22
ZTE CORPORATION
ZTE Plaza, Keji Road South,
Hi-Tech Industrial Park,
Nanshan District, Shenzhen,
P. R. China
518057
Tel: (86) 755 26771900
Fax: (86) 755 26770801
URL: http://ensupport.zte.com.cn
E-mail: support@zte.com.cn

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ZXR10 and is the answer not in the manual?

Questions and answers

Related Manuals for Zte ZXR10

Summary of Contents for Zte ZXR10

  • Page 1 ZXR10 Router/Ethernet Switch Command Manual (QoS Volume) Version 4.8.22 ZTE CORPORATION ZTE Plaza, Keji Road South, Hi-Tech Industrial Park, Nanshan District, Shenzhen, P. R. China 518057 Tel: (86) 755 26771900 Fax: (86) 755 26770801 URL: http://ensupport.zte.com.cn E-mail: support@zte.com.cn...
  • Page 2 The contents of this document are protected by copyright laws and international treaties. Any reproduction or distribution of this document or any portion of this document, in any form by any means, without the prior written consent of ZTE CORPO- RATION is prohibited.

  • Page 3: Table Of Contents

    About This Manual..........i Command Introduction ........1 Manual Use Guide............1 Description of Man-Machine Commands ......1 Auxiliary Function ............2 Command Mode ............. 3 QoS Configuration(Ethernet Switching System).............7 drop-mode tail-drop............7 drop-mode wred............. 8 priority................8 priority-mark ..............9 qos conform-dscp ............10 qos conform-local ............11 qos cos-drop-map ............12...
  • Page 4 QoS configuration(Router Series) ....33 bandwidth ..............34 bgp-policy ..............35 class ................36 class ................36 class-map..............37 clear qos bandwith-statistics ...........38 clear qos queue-statistics ..........39 clear qos statistics ............39 custom-queue-list............40 dos-protect..............40 dos-protect port ............41 dos-protect special ............42 fair-queue ..............42 flow-control ..............43 hierarchy-group ............44 hierarchy-qos..............44 match 802.1p ...............45 match access-group............45...
  • Page 5 priority-list mpls-exp............58 priority-list precedence...........58 priority-list qos-group ............59 priority-list queue-limit...........60 priority-list vlan-id ............61 priority-queue ...............62 qos ip ................62 qos-map ..............62 qos-map enable ............63 queue-list default ............63 queue-list interface............64 queue-list list ..............65 queue-list queue ............65 random-detect ..............66 random-detect ..............70 random-detect enable ............70 random-detect precedence ..........71 random-detect weight ............72 rate-limit(interface) ............72...
  • Page 6 show queueing random-detect ........86 show vpls-car ...............87...

  • Page 7: About This Manual

    Purpose operation of ZXR10 router and Ethernet switch. This manual is intended for engineers and technicians who perform Intended Audience operation activities on ZXR10 router and Ethernet switch. This manual contains the following chapters: What Is in This Manual Chapter...
  • Page 8 ZXR10 Command Manual (QoS Volume) � ZXR10 Router/Ethernet Switch Command Manual (IPv6 Vol- ume) � ZXR10 Router/Ethernet Switch Command Manual (Voice and Video Service Volume) Confidential and Proprietary Information of ZTE CORPORATION...

  • Page 9: Command Introduction

    To search a command, do as follows: 1. Find the desired command by referring to ZXR10 Router/Eth- ernet Switch Command Manual — Command Index. 2. Find command details by the volume, chapter/section and page of the obtained command.

  • Page 10: Auxiliary Function

    Do not describe the history command if this entry does not exist. Auxiliary Function The auxiliary function for ZXR10 devices is as follows. 1. In any command mode, enter a question mark (?) after the DOS prompt of the system, a list of available commands in the command mode will be displayed.

  • Page 11: Command Mode

    ENTER. The ^ is below the first character of the input incorrect command, keyword or parameter. 3. ZXR10 router/Ethernet switch allows the command or key- word to be abbreviated into a character or character string that uniquely identifies this command or keyword. For example, the show command can be abbreviated to sh or sho.
  • Page 12 <1~64 mode mode serial port >(GAR) and telnet connection Layer ZXR10(config- Global acl link Defines layer 2 ACL link-acl)# config- 2 ACL rule config- uration uration mode mode Confidential and Proprietary Information of ZTE CORPORATION...
  • Page 13 Configures ospf OSPFv3 parameters ZXR10(config- Global ip vrf Configures config- vrf)# config- uration uration parameters mode mode VFI con- Global ZXR10(config- Configures figu- config- vfi)# VPLS related ration uration parameters mode mode Confidential and Proprietary Information of ZTE CORPORATION...
  • Page 14 IPSec ZXR10(config- Global ipsec Configures config- config- ipsec)# IPv6 IPSec uration uration protection mode mode Diagno- Privi- diagnose Tests CPU ZXR10(diag)# sis mode leged and memory mode usage Confidential and Proprietary Information of ZTE CORPORATION...

  • Page 15: System)

    ................30 drop-mode tail-drop Use this command to configure port drop policy. Delete this con- Purpose figuration with the no command. Interface configuration Command Modes drop-mode tail-drop <session-index> Syntax no drop-mode Confidential and Proprietary Information of ZTE CORPORATION...

  • Page 16: Drop-Mode Wred

    Description <session-index> Tail drop policy table number, range: 0~4 This command is disabled by default. Defaults It is applied to ZXR10 T160G and ZXR10 5900. Instructions This example describes how to configure tail drop policy table 1. Example ZXR10(config)#interface vlan10...

  • Page 17: Priority-Mark

    The port default priority, range: 0~7, 0 by default The port priority default value is 0. Defaults This command is applied to ZXR10 T160G, ZXR10 5900 and ZXR10 Instructions 3900/3200. This example describes how to set the port default priority as 3.

  • Page 18: Qos Conform-Dscp

    ZXR10 3900/3200 <acl-no> is in the range of 1~299, <rule-no> is in the range of 1~100 This command is applied to ZXR10 T160G, ZXR10 5900 and ZXR10 Instructions 3900/3200 only. This example describes how to configure the port priority related Example to the first rule of ACL 100.

  • Page 19: Qos Conform-Local

    The platform version 4.6.02 and upgrade versions of ZXR10 6900 Instructions switch support this command. RFC defines that the aging time is 24 hours. However, ZXR10 6900 is required to configure this aging time. Considering the actual requirement we make this modification and this makes the aging time of nd stale state be configured.

  • Page 20: Qos Cos-Drop-Map

    (green, yellow or red) determined by three-color mark algorithm. This example describes how to configure conform-local. Example ZXR10(config)#qos conform-local green 0 1 2 3 4 5 6 7 show running-config Related Commands...

  • Page 21: Qos Cos-Local-Map

    The platform version 4.6.02 and upgrade versions support this Instructions command. � It is applied to ZXR10 3900/3200, ZXR10 T160G and ZXR10 5900. � When a switch receives a packet, it will determine the packet cos value first (for the TAG packet, the cos value is the 802.1P...

  • Page 22: Qos Tail-Drop

    The platform version 4.6.02 and upgrade versions support this Instructions command. � It is applied to ZXR10 3900/3200, ZXR10 T160G and ZXR10 5900. � When a switch receives a TAG packet, the packet cos value is the packet 802.1P user priority and the switch determines the packet local priority based on the cos value through this mapping table.

  • Page 23: Qos Wred

    <red-threshold> Drop threshold of red packet, range: 1~256 Defaults <all-threshold> <yellow-threshold> <red-threshold> It is applied to ZXR10T160G and ZXR10 5900. Instructions This example describes how to configure tail-drop. Example ZXR10(config)#qos tail-drop 0 112 112 112 show qos tail-drop Related Command...
  • Page 24 The platform version 4.6.02 and upgrade versions support this Instructions command. � It is applied to ZXR10 3900/3200. � The WRED drops the packets based on the Drop-precedence and the packet with higher drop precedence has a larger prob- ability than the packet with lower drop precedence. Thus, the packet with lower drop precedence possesses higher forward- ing possibility.

  • Page 25: Queue-Mode

    9 by default and it is not sug- gested to be modified. This example describes how to configure WRED. Example ZXR10(config)#qos wred fei 1 queueid 1 10 10 15 10 10 15 10 10 15 show running-config Related...

  • Page 26: Redirect

    Not supported <schedule-unit> Not supported The queue mode is strict-priority by default. Defaults This command is applied to ZXR10 T160G and ZXR10 5900. Instructions This example describes how to set the strict-priority as the queue Example mode. ZXR10(config)#interface vlan10...

  • Page 27: Show Qos

    ZXR10 3900/3200 <acl-number> is in the range of 1~299. <rule-no> is in the range of 1~100. This command is applied to ZXR10 T160G, ZXR10 5900 and ZXR10 Instructions 3900/3200 only. This example describes how to show the ACL 100-related QoS con- Example figuration.

  • Page 28: Show Qos Conform-Dscp

    All modes Command Modes show qos-conform-dscp Syntax � It is applied to ZXR10 3900/3200, ZXR10 T160G and ZXR10 Instructions 5900. � The default mapping table configuration is not displayed. This example describes how to display conform-dscp configuration Example information.

  • Page 29: Show Qos Cos-Local-Map

    Chapter 2 QoS Configuration(Ethernet Switching System) This example describes how to display the information of cos-drop- Example map configuration. ZXR10#show qos-cos-drop qos cos-drop-map 0 1 2 2 1 1 2 2 qos cos-drop-map Related Commands show qos cos-local-map Use this command to set the mapping table between the 802.1P Purpose user priority and the switch local priority.

  • Page 30: Show Qos Wred

    All modes Command Modes show qos-wred Syntax � It is applied to ZXR10 3900/3200. Instructions � The default drop algorithm parameter configuration is not dis- played. This example describes how to display the configuration content Example of WRED policy.

  • Page 31: Traffic-Limit(Interface)

    Chapter 2 QoS Configuration(Ethernet Switching System) � This command is applied to ZXR10 T160G, ZXR10 5900 and Instructions ZXR10 3900/3200. � rule-id <rule-no> is optional. If it is specified, the config- uration and statistics information of this <acl-number> and <acl-no> will be displayed only; otherwise, the rule configura- tion and statistics information of all traffic statistics functions of this <acl-number>...

  • Page 32: Traffic-Limit(Global)

    Use this command to configure traffic policing. Delete the config- Purpose uration with the no command. Global configuration Command Modes The command format on ZXR10 T160G and ZXR10 5900: Syntax traffic-limit {<acl-no>|<acl-name>} rule-id <rule-no> cir <cir-value> cbs <cbs-value>{pir <pir-value> pbs <pbs-value>| ebs <ebs-value>} mode blind | aware [{[remark-red-dp <drop-precedence>][remark-red-dscp...
  • Page 33 (confirm-level: green, yellow, red) and the local-precedence of the packet. remark-drop-prior Rewrites drop-precedence of the packet, green: drop-precedence 0; yellow: drop-precedence 1; red: drop-precedence 2. Confidential and Proprietary Information of ZTE CORPORATION...

  • Page 34: Traffic-Mirror

    ZXR10 3900/3200. � This example describes how to configure traffic policing based Example on Rule 1 in ACL 100 on ZXR10 T160G and ZXR10 5900. ZXR10(config)#traffic-limit 100 rule-id 1 cir 100 cbs 2000 ebs 500000 mode blind � This example describes how to configure traffic policing based on Rule 1 in ACL 100 on ZXR10 3906.

  • Page 35: Traffic-Shape

    1~100. ZXR10 3900/3200 <acl-number> is in the range of 1~299. <rule-nor> is in the range of 1~100. This command is applied to ZXR10 T160G, ZXR10 5900 and ZXR10 Instructions 3900/3200. This example describes how to configure traffic mirroring based on Example Rule 1 in ACL 100.

  • Page 36: Traffic-Statistics

    <rate> Limited rate, range: 650~100000 (100M port) or 650~1000000 (1000M port) <size> Burst size, range: 4~4095 This command is applied to ZXR10 3900/3200 and ZXR10 5900. Instructions This example describes how to configure traffic shaping for the Example incoming interface.

  • Page 37: Trust-Cos

    <acl-numer> and <rule-no>must be defined before this com- Instructions mand is executed. � This command applies to ZXR10 T160G, ZXR10 5900 and ZXR10 3900/3200. This example describes how to configure traffic statistics based on Example Rule 1 in ACL 100.

  • Page 38: Trust-Cos-Local

    | disable Applies DSCP mapping | Disables DSCP mapping. DSCP mapping is not applied by default. Defaults This command is applied to ZXR10 5900 and ZXR10 T160G. Instructions This example describes how to configure port apply DSCP map- Example ping.
  • Page 39 Chapter 2 QoS Configuration(Ethernet Switching System) ZXR10(config-if)#trust-dscp enable qos conform-dscp Related Commands Confidential and Proprietary Information of ZTE CORPORATION...
  • Page 40 ZXR10 Command Manual (QoS Volume) This page is intentionally blank. Confidential and Proprietary Information of ZTE CORPORATION...

  • Page 41: Qos Configuration(Router Series)

    ..............51 police................52 policy-map ...............53 priority................53 priority-group ..............54 priority-list 802.1p.............54 priority-list default .............55 priority-list dscp ..............56 priority-list interface ............56 priority-list list ..............57 priority-list mac..............57 priority-list mpls-exp............58 priority-list precedence............58 priority-list qos-group ............59 priority-list queue-limit............60 Confidential and Proprietary Information of ZTE CORPORATION...

  • Page 42: Bandwidth

    ..............87 bandwidth Use this command to configure the minimum bandwidth of policy. Purpose Cancel the settings with the no command. Policy configuration Command Modes bandwidth {<bandwidth>| percent <percentage>} Syntax no bandwidth <class-map-name> Confidential and Proprietary Information of ZTE CORPORATION...

  • Page 43: Bgp-Policy

    The parameter <bandwidth> is not in the command format for ZXR10 T64E/128. � This command applies to ZXR10 T64E/128 and ZXR10 GER. This example describes how to configure the minimum bandwidth Example of class_1 policy on policy mapping policy_1 as 10%.

  • Page 44: Class

    The class mapping that the parameter <class-map-name> specifies has to be a created one. � This command applies to ZXR10 T64E/T128 and ZXR10 GER. This example describes how to set policy name class_1 in policy Example map policy_1 and enter policy configuration mode.

  • Page 45: Class-Map

    If the current class-map is used by H-QoS, then this class-map Instructions can not be deleted. � This command is applied to ZXR10 T64E/T128 and ZXR10 T600/T1200. This example describes how to create the H-QoS mapping named Example hqos_1, and configure the first layer policy.

  • Page 46: Clear Qos Bandwith-Statistics

    If class map is deleted, all matching rules of the other related class mapping and the policy classes will be deleted at the same time. � This command is applied to ZXR10 T64E/T128 and ZXR10 GER. This example describes how to set class_1 map and enter mapping Example configuration mode.

  • Page 47: Clear Qos Queue-Statistics

    <interface-name> Syntax Syntax Description <interface-name> Name of the specified interface This command is applied to ZXR10 GAR, ZXR10 ZSR and ZXR10 Instructions GER. This example describes how to clear the QoS statistic count on Example interface fei_4/1.

  • Page 48: Custom-Queue-List

    � The platform version 4.6.02 and upgrade versions support this command. � This command is applied to ZXR10 GAR and ZXR10 ZSR only. This example describes how to apply the customized list 1 to the Example interface fei_4/1. ZXR10(config)#interface fei_4/1...

  • Page 49: Dos-Protect Port

    <action> designated rate: drop: discard data packet continue: evaluate next rate-limit command transmit: send data packet This command is applied to ZXR10 GER. Instructions This example describes how to set all interface ICMP packet DOS Example protection function. ZXR10(config)#interface fei_1/1...

  • Page 50: Dos-Protect Special

    Action for the packet exceeding the <action> designated rate: drop: discard data packet transmit: send data packet This command is applied to ZXR10 GER. Instructions This example describes how to set DOS protection function of MAC Example address broadcast packet on all interfaces.

  • Page 51: Flow-Control

    The platform version 4.6.02 and upgrade versions support this Instructions command. � This command is applied to ZXR10 GAR and ZXR10 ZSR only. � This example describes how to apply the WFQ to the inter- Example face fei_4/1, and set the maximal number of messages of each queue to 96 and the number of dynamic queues to the default value.

  • Page 52: Hierarchy-Group

    H-QoS mapping should be created. It is not required to input H-QoS mapping name when deleting. � ZXR10 T64E/T128 and ZXR10 T600/T1200 support this com- mand. This example describes how to create H-QoS mapping named Example hqos_1, and enter H-QoS mapping configuration mode.

  • Page 53: Match 802.1P

    When this interface has been applied with H-QoS mapping, this Instructions H-QoS mapping is not permitted to delete. � ZXR10 T64E/T128 and ZXR10 T600/T1200 supports this com- mand. This example describes how to create H-QoS mapping named as Example hqos_1, and enter into H-QoS mapping configuration mode.

  • Page 54: Match Any

    Syntax Description {<acl-no>|<acl-nam (IPv4)ACL number and name ACL e>} The platform version 4.6.02 and upgrade versions of ZXR10 6900 Instructions switch support this command. In map class_1, set matching access-group and designate a Example matching rule. The matching rule: to match the data flow defined by (IPv4) ACL 10 .

  • Page 55: Match Destination-Address-Mac

    � The parameter <class-map-name> defines the map must be Instructions set already. � This command is applied to ZXR10 T64E/T128. In map class_1, set match access-group and match rule to match Example class_2 data flow. ZXR10(config)#class-map class_1 ZXR10(config-cmap)#match class-map class_2...

  • Page 56: Match Input-Interface

    <input-interface-name> Syntax Description <input-interface-na Input interface name me> This command is applied to ZXR10 GER. Instructions In map class_1, set match access-group and define match rule to Example match the data flow from interface fei_1/1. ZXR10(config)#class-map class_1...

  • Page 57: Match Ip-Precedence

    Syntax Description <ip-precedence-val IP precedence value, range: 0~7 ue> This command is applied to ZXR10 GER and ZXR10 T64E/T128. Instructions In map class_1, set match access group and define matching rule Example to match precedence value 7 data flow. ZXR10(config)#class-map class_1...

  • Page 58: Match Not

    <match-criteria> Syntax Description match-criteria Some matching rule This command is applied to ZXR10 GER. Instructions � This example shows that map class_1 set match access group Example and define the matching rule: not matching the data flow from destination MAC address 1111.2222.3333 .

  • Page 59: Match Qos-Group

    This example describes how to create the matching item and spec- Example ify the matching rule as matching the data flow of vlan-id 10 in class-map class_1. ZXR10(config)#class-map class_1 ZXR10(config-cmap)#match vlan-id 10 class-map Related Commands show class-map Confidential and Proprietary Information of ZTE CORPORATION...

  • Page 60: Police

    � This command is applied to ZXR10 GER and ZXR10 T64E/T128. This example describes how to configure flow inspection for the Example class named class_1 in policy map policy_1. Set the data aver- age rate as 8kbit/s, normal burst as 20000, maximum burst as 200000.

  • Page 61: Policy-Map

    � When the policy mapping is deleted, all policies will be deleted at the same time. � This command is applied to ZXR10 GER and ZXR 10 T64E/T128. This example describes how to set a policy mapping named pol- Example icy_1 and enter policy mapping configuration mode.

  • Page 62: Priority-Group

    � An interface uses only one priority list. Instructions � This command is applied to ZXR10 GAR, ZXR10 GER and ZXR10 T64E/T128 and ZXR10 ZSR. This example describes how to apply the priority list 1 to the in- Example terface fei_4/1.

  • Page 63: Priority-List Default

    For the same <list-number> , the command will specify a new Instructions default queue in the next time. This command is applied to ZXR10 GAR, ZXR10 GER, ZXR10 T64E/T128 and ZXR10 ZSR. This example describes how to specify a queue with low priority Example for the packet that does not match any rules in the priority list 1.

  • Page 64: Priority-List Dscp

    Designated DSCP value, range: 0~63 Priority queue high | medium | normal | low This command is applied to ZXR10 GAR, ZXR10 GER, ZXR10 Instructions T64E/T128 and ZXR10 ZSR. This example describes how to specify a queue with low priority Example for the packet with the DSCP value 10 in priority-list 1.

  • Page 65: Priority-List List

    Chapter 3 QoS configuration(Router Series) This command is applied to ZXR10 GAR, ZXR10 GER and ZXR10 Instructions ZSR. This example describes how to specify a queue with low priority Example for the packet entering the interface fei_4/1 in priority-list 1.

  • Page 66: Priority-List Mpls-Exp

    Designated MPLS-EXP value, range: 0~7 -value> high | medium | Priority queue normal | low This command is applied to ZXR10 GAR, ZXR10 GER, ZXR10 Instructions T64E/T128 and ZXR10 ZSR. This example describes how to specify a queue with low priority Example for the packet with the MPLS-EXP value 7 in priority-list 1.

  • Page 67: Priority-List Qos-Group

    Designated IP precedence value, range: 0~7 <precedence> Priority queue high | medium | normal | low This command is applied to ZXR10 GAR, ZXR10 GER, ZXR10 Instructions T64E/T128 and ZXR10 ZSR. This example describes how to specify a queue with low priority Example for the packet with the IP precedence value 7 in priority-list 1.

  • Page 68: Priority-List Queue-Limit

    Value range: 0~128, 40 by default ZXR10 GER Value range: 0~128, 90 by default ZXR10 ZSR Value range: 0~128, 40 by default Product Description of <normal-limit> ZXR10 GAR Value range: 0~128, 60 by default Confidential and Proprietary Information of ZTE CORPORATION...

  • Page 69: Priority-List Vlan-Id

    Defaults ber of packets in the queue with different priorities in the priority list is the default value. This command is applied to ZXR10 GAR, ZXR10 GER and ZXR10 Instructions ZSR. This example describes how to set the maximal number of packets...

  • Page 70: Priority-Queue

    Global configuration Command Modes qos ip Syntax no qos ip This command is applied to ZXR10 GAR, ZXR10 GER, ZXR10 Instructions T64E/T128 and ZXR10 ZSR. This example describes how to enable the QoS function. Example ZXR10(config)#qos ip...

  • Page 71: Qos-Map Enable

    Interface configuration Command Modes qos-map {enable | disable} Syntax Disable Defaults This command is applied to ZXR10 GER. Instructions This example describes how to enable QoS mapping on the inter- Example face. ZXR10(config)#interface fei_4/1 ZXR10(config-if)#qos-map enable...

  • Page 72: Queue-List Interface

    The platform version 4.6.02 and upgrade versions support this Instructions command. � This command is applied to ZXR10 GAR and ZXR10 ZSR. This example describes how to specify the customized queue 2 for Example the packet that does not match any rules in the customized list 1.

  • Page 73: Queue-List List

    The platform version 4.6.02 and upgrade versions support this Instructions command. � This command is applied to ZXR10 GAR and ZXR10 ZSR. This example describes how to specify the customized queue 2 for Example the packet with ACL number 10 in the customized list 1.

  • Page 74: Random-Detect

    The platform version 4.6.02 and upgrade versions support this Instructions command. � This command is applied to ZXR10 GAR and ZXR10 ZSR. � This example describes how to set the maximal number of Example packets of the user-defined queue 2 to 30 in customized list 1 and set the maximal number of bytes to the default value.
  • Page 75 Optional ZXR10 GER Not selectable ZXR10 ZSR optional ZXR10 T64E/T128 Not selectable Product Description of <exponent> ZXR10 GAR Value range: 1~16, 3 by default ZXR10 ZSR Value range: 1 ~16, 3 by default Confidential and Proprietary Information of ZTE CORPORATION...
  • Page 76 Description of <max-threshold> ZXR10 GAR Value range: 1~16, 40 by default ZXR10 ZSR Value range: 1~16, 40 by default ZXR10 GER Value range: 1~112, no default value ZXR10 T64E/T128 Value range: 1~64, no default value Confidential and Proprietary Information of ZTE CORPORATION...
  • Page 77 This example describes how to enable the WRED on the inter- Example face fei_4/1 on ZXR10 ZSR and ZXR10 GAR, set the exponent used to compute the average queue length, minimal/maximal threshold value of the average queue length of different prior- ities and discard probability to their default values.

  • Page 78: Random-Detect

    ZXR10 Command Manual (QoS Volume) ity to 30 of the average queue length with priority value as 2 on the interface fei_4/1 on ZXR10 T64E/T128. ZXR10(config)#interface fei_4/1 ZXR10(config-if)#random-detect precedence 2 20 40 30 For ZXR10 GAR and ZXR10 ZSR, Related...

  • Page 79: Random-Detect Precedence

    <mark-prob-denomin Denominator of discard probability, range: ator> 1~100 � This command is applied to ZXR10 T64E/T128. Instructions � Enable WRED discard policy by using the command random- detect prec-based first, then use this command. This example describes how to configure policy map policy_1: set...

  • Page 80: Random-Detect Weight

    Enable WRED discard policy firstly by using the command rand Instructions om-detect , then use this command. � This command is applied to ZXR10 T64E/T128. This example describes how to confiure policy map policy_1: set Example the name to class_1, set the denominator for accounting average queue length to 7.
  • Page 81 Sets an IP precedence value (0 ~ 7) and sends the packet exceed-action Actions for the packet exceeding the <action> designated rate: drop: Discards the packet continue: Evaluates the next rate-limit command transmit: Sends the packet Confidential and Proprietary Information of ZTE CORPORATION...
  • Page 82 ZXR10 T64E/T128 No such a parameter This command is applied to ZXR10 GAR, ZXR10 GER, ZXR10 Instructions T64E/T128 and ZXR10 ZSR. This example describes how to set the rate of traffic with DSCP...

  • Page 83: Rate-Limit(Global Configuration)

    Sets an IP precedence value (0 ~ 7) and sends the packet exceed-action Actions for the packet exceeding the <action> designated rate: drop: Discards the packet continue: Evaluates the next rate-limit command Confidential and Proprietary Information of ZTE CORPORATION...

  • Page 84: Service-Policy

    PQ, CAR, WRED configu- rations can not be restored. � This command is applied to ZXR10 GER and ZXR10 T64/T128. � ZXR10 T64E/T128 does not have the parameter output. This example describes how to configure interface fei_1/1 output Example direction bound policy map policy_1.

  • Page 85: Set Dot1P

    Syntax Description <dot1p-value> 802.1p value, range: 0~7 This command is applied to ZXR10 GER. Instructions This example describes how to configure policy map policy_1 name Example class_1 policy class, and use value 7 to mark message 802.1p field.

  • Page 86: Set Ip-Precedence

    Instructions � This command is applied to ZXR10 GER. This example describes how to configure policy map policy_1: set Example the name to class_1 policy class, and use value 7 to mark message IP precedence field.

  • Page 87: Show Class-Map

    If the parameter <class-map-name> needs to specify, the class map has to be a created class map. � This command is applied to ZXR10 T64E/T128. This example describes how to show name class_1 class map and Example all matched configuration.

  • Page 88: Show Flow-Contrl

    [<hierarchy-qos-name>] Syntax Syntax Description <hierarchy-qos-na H-QoS mapping name me> This command is applied to ZXR10 T64E/T128 and ZXR10 Instructions T600/1200. This example describes how to display H-QoS mapping named Example hqos_1. ZXR10(config)#show hierarchy-qos hqos_1 hierarchy-qos hqos_1 class c1 8000 20000 20000 conform-action transmit...

  • Page 89: Show Policy-Map

    <class-map-name> is also specified, the specified class map and its policy configurations will be shown only. � This command is applied to ZXR10 T64E/T128 and ZXR10 GER. � This example describes how to show all policy maps and policy Example configurations.

  • Page 90: Show Qos Class-Map

    � The platform version 4.8.21 and the upgrade version support Instructions this command. � This command is applied to ZXR10 T64E/T128 and ZXR10 T600/1200. � This example describes how to show the statistic information Example of bandwidth policy on interface fei_4/1.

  • Page 91: Show Qos Config Vrf

    VRF is shown. � The VRF has to be created before. Instructions � This command is applied to ZXR10 T64E/T128 and ZXR10 T600/T1200. This example describes how to display the QoS configuration on Example interface fei_4/1 which belongs to vrf_1.

  • Page 92: Show Qos Queue-Statistics

    � The platform versions 4.8.21 and upgrade version support this Instructions command. � This command is applied to ZXR10 T64E/T128 and ZXR10 T600/T1200. � This example describes how to display the statistic information Example of queue policy on interface fei_4/1.

  • Page 93: Show Queueing Custom

    � The platform version 4.6.02 and upgrade versions support this Instructions command. � This command is only applied to ZXR10 GAR, ZXR10 ZSR. This example describes how to show the configuration information Example of all user-defined lists. ZXR10(config)#show queueing custom...

  • Page 94: Show Queueing Interface

    The platform version 4.6.02 and upgrade versions support this Instructions command. � This command is applied to ZXR10 GAR and ZXR10 ZSR. This example describes how to show the congestion management Example policy information and statistics of fei_4/1. ZXR10(config)#show queueing interface fei_4/1...

  • Page 95: Show Vpls-Car

    The platform version 4.6.02 and upgrade versions support this Instructions command. � This command is applied to ZXR10 GAR and ZXR10 ZSR. This example describes how to show the WRED configuration and Example statistical information of all WRED-enabled interfaces. ZXR10(config)#show queuing random-detect...
