UG-240

ORDERING INFORMATION

BILL OF MATERIALS

Table 1.
Quantity
Reference Designator
2 R1, R2
1 RT
2 C1, C2
2 J1, J2
1 J3
1 J4
1
LK1
1 U3
2 GND1, GND2
2 VDD1, VDD2
2 A, B
7
RXD, DE, RE, PV, TXD, PV1, DE/RTS

RELATED LINKS

Resource Description
ADM2486 Product Page, 2.5 kV Signal Isolated, High Speed (20 Mbps), Half Duplex RS-485 Transceiver
AN-960 RS-485/RS-422 Circuit Implementation Guide
Description
Resistor, 390 Ω, 0805
Resistor, 220 Ω, 0805
Capacitor, Size 0805, 100 nF
CON\POWER, 2-pin terminal block (5 mm pitch)
CON\POWER, terminal block, PCB, 3-way
CON\POWER4, 4-pin terminal block
Board-to-board connector header, 4-way,
2-row and Jumper ×2
SO16WB
Test point, black
Test point, red
Test point, green
Test point, yellow
www.BDTIC.com/ADI
Rev. 0 | Page 6 of 8
Evaluation Board User Guide
Supplier/Part Number
Vishay Dale/CRCW0805390RJNEA
Yageo/RC0805JR-07220RL
AVX Corp./08055C104KAT2A
Lumberg/KRM 02
Lumberg/KRM 03
Lumberg/KRM 04
SPC Technology/SPC20499
HARWIN/M7566-05
Analog Devices/ADM2486BRWZ
Vero Technologies/20-2137
Vero Technologies/20-313137
Vero Technologies/20-313138
Vero Technologies/20-313140
