7.1.4 Pitch & Catch Operating Procedure
To release control of the crane, press the "Pitch" push button. To take over control of the crane,
rotate the power key switch to "Catch" position for up to 2 seconds. The 2
take control of the crane unless the 1
If the operator unintentionally presses the "Pitch" push button during operation, just rotate the
power key to "Catch" position for up to 2 seconds to regain control again.

7.1.5 Automatic Channel Scanning Operating Procedure

After changing the transmitter channel (refer to page 17), turn on the transmitter power and
rotate the power key switch to "Start" position and hold it there for up to 1 minute. Within this 1-
minute period the receiver will search (channel 01 ~ channel 62) and lock onto the newly
selected transmitter channel automatically. Please note that in order for the receiver to switch to
auto-scanning mode, prior to changing the transmitter channel, you must first deactivate the
receiver MAIN by shutting off the transmitter power or press down the emergency stop button.
Please refer to page 33 if you do not want the receiver to auto-scan all 62 channels.
Change Transmitter Channel

7.1.6 Changing Transmitter Batteries

Change the transmitter batteries by unscrewing the battery cover located on the backside of the
transmitter (refer to Fig. 20 below). During battery installation make sure that the blue ribbon is
centered between the two batteries. After changing the batteries also make sure that all screws
are tightened to avoid water, moisture, dirt, grease, or other liquid penetration.
st
operator presses the "Pitch" push button (2.0 seconds).
→
→
(Fig. 20)
nd
operator cannot
→
2
1
↓
