3. GENERAL SYSTEM INFORMATION
3.1 TRANSMITTER HANDSET
3.1.1 External Illustration (Standard Push Button Configuration)
1. Emergency Stop Button
2. Removable Power Key Switch 9.
3. Push Button #2
4. Push Button #4
5. Push Button #6
6. Push Button #8
7. Push Button #10
(Fig. 01)
8.
Push Button #12
Push Button #1
10.
Push Button #3
11.
Push Button #5
12.
Push Button #7
13.
Push Button #9
14.
Push Button #11
(Fig. 02)
15.
Strap Ring
16.
System Information
17.
System Channel
18.
Crane Number
19.
Battery Cover
20.
FCC Information
Flex 12EX System Instruction Manual
December 2013
Page 13 of 48
