Specifications, Accessories, and Part Numbers, cont'd
Included Parts
These items are included in each order for a specific TP
transmitter:
Included parts
TP T 15HD A
TP Transmitters Family User's Guide
Single output external power supply, 15 V, 0.8 A
Captive screw connector, 3 pole, 3.5 mm
TP T 15HD AV
TP Transmitters Family User's Guide
Single output external power supply, 15 V, 0.8 A
Captive screw connector, 3 pole, 3.5 mm
TP T 468
TP T 468 (gray)
TP T 468 (black)
TP T 468 (white)
TP T 468 (EC)
TP Transmitters Family User's Guide
Single output external power supply, 15 V, 0.8 A
4-gang mud ring (gray, black, white)
TP T BNC DA4
TP Transmitters Family User's Guide
Single output external power supply, 15 V, 0.8 A
Captive screw connector, 3 pole, 3.5 mm
The TP T 15HD AV is a redesigned transmitter. The
audio portion of the composite video TP link can be
configured to work with the similarly redesigned
TP R BNC AV receiver or with older, unmodified
receivers. See "Audio jumpers" in chapter 2,
"Installation and Operation." Redesigned transmitters
and receivers have an identifying label.
A-6 Extron TP Transmitters • Specifications, Accessories, and Part Numbers
Replacement part number
60-345-02
70-057-01
10-265-03
60-346-03
70-057-01
10-265-03
60-434-01
60-434-02
60-434-03
60-434-10
68-546-03
70-057-01
70-086-03, -13, -23
60-349-02
70-057-01
10-265-03
Accessories
Accessory
P/S 150 Multiple output 15V power supply
Extron 9.5" Deep 1U Rack Shelf kit (RSU 129)
Extron 9.5" Deep 1U Basic Rack Shelf (RSB 129)
Extron TP Rack Mounting Kit (RSM 100)
Extron Under Desk Mounting Kit (MBU 125)
Extron Through-desk Mounting Kit (MBD 129)
4-gang "J" box 2.5" (6.4 cm) deep

Cables and Adapters

Skew-Free™ A/V UTP cables are not recommended for
Ethernet/LAN applications.
Skew-Free™ A/V cable
UTP 23SF-4/3 — 3' (90 cm)
UTP 23SF-4/6 — 6' (1.8 cm)
UTP 23SF-4/12 — 12' (3.6 m)
UTP 23SF-4/25 — 25' (7.6 m)
UTP 23SF-4/35 — 35' (10.6 m)
UTP 23SF-4/50 — 50' (15.2 m)
UTP 23SF-4/75 — 75' (22.8 m)
UTP 23SF-4/100 — 100' (30.4 m)
UTP23SF-4P/25 — 25' (7.6 m) plenum
UTP23SF-4P/35 — 35' (10.6 m) plenum
UTP23SF-4P/50 — 50' (15.2 m) plenum
UTP23SF-4P/75 — 75' (22.8 m) plenum
UTP23SF-4P/100 — 100' (30.4 m) plenum
UTP23SF-4P/150 — 150'(45.7 m) plenum
UTP23SF-4P/200 — 200' (61 m) plenum
UTP23SF-4P/250 — 250' (76.2 m) plenum
UTP23SF-4P/300 — 300' (91.4 m) plenum
Extron TP Transmitters • Specifications, Accessories, and Part Numbers
Part number
60-432-01
60-190-01
60-604-02
70-123-01
70-077-01
70-077-02
980097
Part number
26-569-01
26-569-02
26-569-03
26-569-04
26-569-05
26-569-06
26-569-07
26-569-08
26-570-04
26-570-05
26-570-06
26-570-07
26-570-08
26-570-09
26-570-10
26-570-11
26-570-12
A-7
