- Page 1 User Guide Twisted Pair MTP T 15HD A Architectural Twisted Pair Transmitters MTP T 15HD WM, MTP T 15HD A D, MTP T 15HD A AAP 68-2207-01 Rev. B 04 13...
-
Page 2: Safety Instructions
Safety Instructions Safety Instructions • English Chinese Simplified （简体中文） 警告： 产品上的这个标志意在警告用户该产品机壳内有暴露的危险 WARNING: This symbol, , when used on the product, is intended to alert the user of the presence of uninsulated dangerous voltage within 电压， 有触电危险。 the product’s enclosure that may present a risk of electric shock. 注... - Page 3 “ Extron Safety and Regulatory ” on the Extron website. Compliance Guide Copyright © 2013 Extron Electronics. All rights reserved. Trademarks All trademarks mentioned in this guide are the properties of their respective owners. (SM) (TM)
- Page 4 Conventions Used in this Guide Notifications The following notifications are used in this guide: WARNING: A warning indicates a situation that has the potential to result in death or severe injury. ATTENTION: Attention indicates a situation that may damage or destroy the product or associated equipment.
-
Page 5: Table Of Contents
About the MTP Transmitters ....... 1 Twisted Pair Cable Advantages ....... 1 Transmission Distance ........1 About the MTP T 15HD A WM ......3 About the MTP T 15HD A D ......4 About the MTP T 15HD A AAP ....... 4 Installation ............. -
Page 7: Introduction
MTP RL 15HD A SEQ receiver. A pre-peaking control switch boosts the transmission distance of the proprietary signal. The MTP T 15HD A architectural series is part of a system for long-distance distribution of VGA or other high resolution video and audio, over Extron Enhanced Skew-Free AV UTP Cable, or any CAT 5, 5e, or 6 shielded twisted pair (STP), unshielded twisted pair (UTP), or foil shielded twisted pair (FTP) cable. - Page 8 Resolutions marked with an asterisk (*) in the table above have the same range specifications at 75 Hz. • It is possible to exceed the recommended distance, but image quality may be reduced. MTP T 15HD A Architectural Series • Introduction...
-
Page 9: About The Mtp T 15Hd A Wm
About the MTP T 15HD A WM The MTP T 15HD A WM Twisted Pair Transmitter is a wall or furniture mountable version of the MTP T 15HD A, and can be mounted into any standard Underwriters Laboratories (UL) listed one-gang electrical wall box or by using the included mud ring. -
Page 10: About The Mtp T 15Hd A D
About the MTP T 15HD A D The MTP T 15HD A D Twisted Pair Transmitter is a wall or furniture mountable version of the MTP T 15HD A that fits any Decora® style wall plate. AUDIO IN COMPUTER IN Figure 3. -
Page 11: Installation
Installing the MTP T 15HD A WM and MTP T 15HD A D The MTP T 15HD A WM and MTP T 15HD A D can be installed in a one-gang electrical wall box, with the MTP T 15HD A D fitting into a Decora wall plate cover (supplied). If a suitable wall box is already installed, follow steps 5 through 8 on the following page. -
Page 12: Installing Into A Mud Ring (Wm And Decora Models)
Final Installation on page 7. Wall Wall Mounting Bracket (mud ring) D IO IN P MTP T 15HD A WM Figure 5. Mounting the MTP T 15HD A WM Using the Mud Ring MTP T 15HD A Architectural Series • Installation... -
Page 13: Final Installation
Installing the Wall Box • If installing an MTP T 15HD A WM, mount the faceplate directly to the box or mud ring. • If installing an MTP T 15HD A D, mount it directly to the wall box, then attach the Decora wall plate, as shown in figure 7, and restore the power supply. -
Page 14: Installing The Mtp T 15Hd A Aap
Installing the MTP T 15HD A AAP The MTP T 15HD A AAP must be attached to a device faceplate or AAP wall plate and cabled before the device or wall plate is pretested or installed in a wall or furniture. -
Page 15: Connections And Settings
Potential damage to property. Do not connect these devices to a computer data or telecommunications network. Front Panel Features The front panel features are the same on all the MTP T 15HD A architectural models, as shown in figure 9. AUDIO IN... -
Page 16: Rear Panel Features
Rear Panel Features With the exceptions of , and on the MTP T 15HD A D , as noted in the figures and descriptions, the rear panel features are the same on all the MTP T 15HD A architectural models. PRE- PEAK... -
Page 17: Power Supply Wiring And Grounding
Extron twisted pair product by following the diagram in figure 13 on the next page. Ground the power port by inserting one end of the grounding wire to the negative or ground pin on the power input connector. MTP T 15HD A Architectural Series • Installation... - Page 18 Use the supplied tie wrap to strap the power cord to the extended tail of the connector. As an alternative, an Extron PS 124 Universal 12 VDC Power Supply can power multiple MTPs or other Extron 12 VDC devices using only one AC power connector. MTP T 15HD A Architectural Series • Installation...
-
Page 19: Twisted Pair Cable Termination
RGB signals. • The orange wire pair of this cable has a different length and should not be used to transmit the RGB signals. MTP T 15HD A Architectural Series • Installation... -
Page 20: Edid Minder Configuration
EDID Minder Configuration The MTP T 15HD A D unit supports emulation of factory-installed EDID information through EDID Minder. To use factory-installed EDID information: If you have not already done so, connect the source device to the MTP 15HD transmitter. Do not power on the source device at this time. -
Page 21: Reference Information
Information This section includes a template with cut-out dimensions for installation of the MTP T 15HD A WM or MTP T 15HD A D transmitter. Decora Template Dimensions Use the dimensions in the cut-out template in figure 16 as a guide for cutting a hole in a wall or furniture. - Page 22 Extron Electronics makes no further warranties either expressed or implied with respect to the product and its quality, performance, merchantability, or itness for any particular use. In no event will Extron Electronics be liable for direct, indirect, or consequential damages resulting from any defect in this product even if Extron Electronics has been advised of such damage.
