Owner's Operator and Maintenance Manual
Xtra™
DEALER: This manual MUST be given to
the user of the wheelchair.
USER: BEFORE using this wheelchair, read
this manual and save for future reference.
For more information regarding
Invacare products, parts, and services,
please visit www.invacare.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XtraTM 1026793 and is the answer not in the manual?

Questions and answers

Related Manuals for Invacare XtraTM 1026793

Summary of Contents for Invacare XtraTM 1026793

  • Page 1 Owner’s Operator and Maintenance Manual Xtra™ DEALER: This manual MUST be given to the user of the wheelchair. USER: BEFORE using this wheelchair, read this manual and save for future reference. For more information regarding Invacare products, parts, and services, please visit www.invacare.com...
  • Page 2 APPLICABLE). IF YOU ARE UNABLE TO UNDERSTAND THE WARNINGS, CAUTIONS AND INSTRUCTIONS, CONTACT INVACARE TECHNICAL SUPPORT BEFORE ATTEMPTING TO SERVICE OR OPERATE THIS EQUIPMENT - OTHERWISE, INJURY OR DAMAGE MAY RESULT. NOTE: Updated versions of this manual are available on www.invacare.com. Xtra™ Part No 1026793...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS SPECIAL NOTES ... 9 LABEL LOCATIONS ... 10 TYPICAL PRODUCT PARAMETERS ... 11 SECTION 1—GENERAL GUIDELINES ... 12 Stability...12 Repair and Service Information...13 Operating Information...13 Tire Pressure ...15 Weight Training ...15 Weight Limitation...15 SECTION 2—SAFETY/HANDLING OF WHEELCHAIRS ... 16 Stability and Balance...16 Coping with Everyday Obstacles ...17 A Note to Wheelchair Assistants ...17...
  • Page 4 TABLE OF CONTENTS SECTION 4—FRONT RIGGINGS ... 28 Installing/Removing/Adjusting the Footrests ...28 Swingaway Front Frame ...28 Adjusting 70° MFX and 90° Footrests ...29 Installing Elevating Legrests ...30 Raising/Lowering Elevating Legrests...30 Adjusting Calfpads ...31 Installing Adjustable Angle Flip-Up Footplate Hinge ...31 Adjusting Adjustable Angle Flip-Up Footplates ...32 Depth Adjustment ...32 Angle Adjustment ...32...
  • Page 5 TABLE OF CONTENTS SECTION 7—ARMS ... 42 Installing the Half Arm...42 Adjusting Half Arm Height ...43 Using/Adjusting Dual Point Arms ...44 Adjusting Armrest Height ...44 Removing Armrests...44 Replacing Armrests...44 Replacing Dual Point Arm Pad/Clothing Guards...45 Replacing Arm Pad...45 Replacing Clothing Guards ...45 Installing/Removing T-Arms ...45 Installing T-Arms ...45 Removing T-Arms...46...

  • Page 6: Register Your Product

    3. Receive updates with product information, maintenance tips, and industry news. 4. Invacare can contact you or your provider, if servicing is needed on your product. 5. It will enable Invacare to improve product designs based on your input and needs.

  • Page 7: Product Registration Form

    11. User's Year of birth: ______________________________________________________ If at any time you wish not to receive future mailings from us, please contact us at Invacare Corporation, CRM Department, 39400 Taylor Parkway, Elyria, OH 44035, or fax to 877-619-7996 and we will remove you from our mailing list.
  • Page 8 Fold here Fold here Invacare Product Registration Form Please Seal with Tape Before Mailing...

  • Page 9: Special Notes

    CHANGE WITHOUT NOTICE. WHEELCHAIR USER As a manufacturer of wheelchairs, Invacare endeavors to supply a wide variety of wheelchairs to meet many needs of the end user. However, final selection of the type of wheelchair to be used by an individual rests solely with the user and his/her healthcare professional capable of making such a selection.

  • Page 10: Label Locations

    LABEL LOCATIONS LABEL LOCATIONS Xtra only Xtra Heavy Duty only Manual Title Part No...

  • Page 11: Typical Product Parameters

    TYPICAL PRODUCT PARAMETERS OVERALL WIDTH (WITH 0º CAMBER) OPEN - Seat width plus approximately 8-1/2 inches CLOSED - approximately 12 inches OVERALL DEPTH Seat depth plus 14 inches (Without Front Riggings) SEAT WIDTH 14 to 22 inches SEAT DEPTH 14 to 22 inches REAR FRAME TYPE Square FRONT FRAME...

  • Page 12: Section 1-General Guidelines

    SECTION 1—GENERAL GUIDELINES SECTION 1 - GENERAL GUIDELINES contains important information for the safe operation and use of this product. DO NOT use this product or any available optional equipment without first completely reading and understanding these instructions and any additional instructional material such as Owner’s Manuals, Service Manuals or Instruction Sheets supplied with this product or optional equipment.

  • Page 13: Repair And Service Information

    SECTION 1—GENERAL GUIDELINES Repair and Service Information Unless otherwise noted, all service and adjustments should be performed while the wheelchair is unoccupied. Operating Information To determine and establish your particular safety limits, practice bending, reaching and transferring activities in several combinations in the presence of a qualified health professional BEFORE attempting active use of the wheelchair.
  • Page 14 ALWAYS use the handrims for self-propulsion. Inasmuch as the handrims are an option on this wheelchair (you may order with or without the handrims), Invacare strongly recommends ordering the handrims as an additional safeguard for the wheelchair user. Xtra™...

  • Page 15: Tire Pressure

    Invacare DOES NOT recommend the use of its wheelchairs as a weight training apparatus. Invacare wheelchairs have NOT been designed or tested as a seat for any kind of weight training. If occupant uses said wheelchair as a weight training apparatus, Invacare shall not be liable for bodily injury and the warranty is void.

  • Page 16: Section 2-Safety/Handling Of Wheelchairs

    Individual wheelchair users often develop skills to deal with daily living activities that may differ from those described in this manual. Invacare recognizes and encourages each individual to try what works best for him/her in overcoming architectural obstacles that they may encounter, however ALL WARNINGS and CAUTIONS given in this manual MUST be followed.

  • Page 17: Coping With Everyday Obstacles

    Virtually all activities which involve movement in the wheelchair have an effect on the center of gravity. Invacare recommends using seat/chest positioning straps for additional safety while involved in activities that shift your weight.

  • Page 18: Tipping

    Tipping DO NOT tip the wheelchair without assistance. When tipping the wheelchair, an assistant should grasp the back of the wheelchair on a non-removable (non-detachable) part. Inform the wheelchair occupant before tipping the wheelchair and remind him/her to lean back. Be sure the occupant’s feet and hands are clear of all wheels.

  • Page 19: Stairways

    Extreme caution is advised when it is necessary to move an occupied wheelchair up or down the stairs. Invacare recommends that, if possible, the user be removed from the wheelchair prior to moving. Invacare recommends using two (2) assistants and making thorough preparations.

  • Page 20: Transferring To And From Other Seats

    3. The second assistant, with a firm hold on a non-detachable part of the framework, lifts the wheelchair up and over the stair and steadies the wheelchair as the first assistant places one (1) foot on the next stair and repeats STEP 1. 4.

  • Page 21: Percentage Of Weight Distribution

    Percentage of Weight Distribution DO NOT attempt to reach objects if you have to move forward in the seat or pick them up from the floor by reaching down between your knees. The seat depth, seat dump, back angle, seating system, size/position of the rear wheels, size/position of the front casters, as well as the user condition directly relate to the stability of the wheelchair.

  • Page 22: Reaching, Leaning And Bending - Forward

    Reaching, Leaning and Bending - Forward DO NOT attempt to reach objects if you have to move forward in the seat or pick them up from the floor by reaching down between your knees. NOTE: For this procedure, refer to FIGURE 2.6. Position the casters so that they are extended away from the drive wheels and engage wheel locks.

  • Page 23: Section 3-Safety Inspection/ Troubleshooting

    SECTION 3—SAFETY INSPECTION/ TROUBLESHOOTING NOTE: Twice a year or every six (6) months, take your wheelchair to a qualified dealer for a thorough inspection and servicing. Regular cleaning will reveal loose or worn parts and enhance the smooth operation of your wheelchair. To operate properly and safely, your wheelchair must be cared for just like any other vehicle.

  • Page 24: Inspect/Adjust Weekly

    As with any vehicle, the wheels/casters and tires should be checked periodically for cracks, flat spots and wear, and should be replaced. Loosen/tighten locknut if wheel wobbles noticeably or binds to a stop. Wheel bearings are clean and free of moisture. Ensure all caster/wheel/fork/headtube fasteners are secure.
  • Page 25 Inspect/Adjust Monthly Inspect seat positioning strap for any signs of wear. Ensure buckle latches. Verify hardware that attaches strap to frame is secure and undamaged. Replace if necessary. Loosen/tighten locknut if wheel wobbles noticeably or binds to a stop. Wheel bearings are clean and free of moisture. Wheel locks do not interfere with tires when rolling.

  • Page 26: Troubleshooting

    Clean quick-release axles with a Teflon Ensure axles are free from dirt, lint, etc. Ensure roller bearings are free from dirt, lint, etc. Adjust wheel locks as tires wear. Clean and wax all parts. Troubleshooting Maintenance After adjustments and BEFORE use, make sure all attaching hardware is securely tightened, otherwise injury or damage may result.

  • Page 27: Suggested Maintenance Procedures

    Suggested Maintenance Procedures 1. Before using your Invacare Xtra wheelchair, make sure all nuts and bolts are tight. Check all parts for damage or wear and replace. Check all parts for proper adjustment. DO NOT use WD-40®, 3-in-1 oil®, or other penetrating lubricants on quick-release axles.

  • Page 28: Section 4-Front Riggings

    SECTION 4—FRONT RIGGINGS After any adjustments, repair or service and before use, make sure all attachment hardware is tightened securely - otherwise, injury or damage may result. Installing/Removing/Adjusting the Footrests Swingaway Front Frame NOTE: For this procedure, refer to FIGURE 4.1. Installing/Removing NOTE: Remove the footrests from the wheelchair by reversing this procedure.

  • Page 29: Adjusting 70° Mfx And 90° Footrests

    Installing/Removing Footrest Mounting Pin Footrest Release Lever FIGURE 4.1 Installing/Removing/Adjusting the Footrests - Swingaway Front Frame Adjusting 70° MFX and 90° Footrests NOTE: For this procedure, refer to FIGURE 4.2. 1. Remove any accessories that are attached to the footrests. 2.

  • Page 30: Installing Elevating Legrests

    Installing Elevating Legrests NOTE: For this procedure, refer to FIGURE 4.3. 1. Insert the pivot tube into the legrest support and secure it with the bolt and nut. 2. Place legrest on the outside of the wheelchair and insert the mounting pin into the mounting tube.

  • Page 31: Adjusting Calfpads

    Adjusting Calfpads NOTE: For this procedure, refer to FIGURE 4.5. 1. To adjust the calfpad, turn pad towards the outside of the wheelchair. 2. Slide the calfpad up or down until the desired position is obtained. 3. To secure the calfpad, turn the calfpad towards the inside of the wheelchair.

  • Page 32: Adjusting Adjustable Angle Flip-Up Footplates

    Adjusting Adjustable Angle Flip-Up Footplates When determining the angle of the footplates, make sure the rear of the footplates DO NOT interfere with the movement of the front casters. Otherwise, injury or damage may occur. NOTE: For this procedure, refer to FIGURE 4.7. Depth Adjustment 1.

  • Page 33: Heel Loop Replacement

    Heel Loop Replacement NOTE: For this procedure, refer to FIGURE 4.8. 1. Remove the hex screw and coved washer that secures the lower half of the footrest to the swingaway footrest assembly. 2. Remove the lower footrest assembly. 3. Remove the phillips screw and locknut that secure the heel loop to the footrest.

  • Page 34: Section 5-Back

    SECTION 5—BACK After any adjustments, repair or service and before use, make sure all attachment hardware is tightened securely - otherwise, injury or damage may result. Adjusting the Back Height NOTE: For this procedure, refer to FIGURE 5.1. NOTE: There are four (4) height ranges of back canes available - 14-18-inches (10° bend and straight back canes), 10-14-inches (sportster without push handles), 12-16-inches (straight with push handles) and 20-inches (10°...

  • Page 35: Adjusting The Back Angle

    Adjusting the Back Angle NOTE: For this procedure, refer to FIGURE 5.2. NOTE: This procedure applies to adjustable angle backs only. NOTE: The back adjusts to four (4) positions in five 5° degree increments from 0° to 15°. 1. Remove the two (2) back angle adjustment screws and locknuts. 2.

  • Page 36: Installing/Removing The Chest Positioning Strap

    Installing/Removing the Chest Positioning Strap NOTE: For this procedure, refer to FIGURE 5.3. 1. Remove the two (2) mounting screws and washers securing the back upholstery to the back cane. 2. Do one (1) of the following: A. To install the chest positioning strap, proceed to STEP 3.

  • Page 37: Installing The Stroller Handles

    Invacare products are specifically designed and manufactured for use in conjunction with Invacare accessories. Accessories designed by other manufacturers have not been tested by Invacare and are not recommended for use with Invacare products. 1. Ensure that the seating system is compatible with this wheelchair.

  • Page 38: Section 6-Seat

    SECTION 6—SEAT After any adjustments, repair or service and before use, make sure all attachment hardware is tightened securely - otherwise, injury or damage may result. Folding/Unfolding the Wheelchair DO NOT sit or transfer into the wheelchair unless it is fully open and the seat rails are fully seated into the seat clamps.

  • Page 39: Replacing Seat Upholstery

    Replacing Seat Upholstery NOTE: For this procedure, refer to FIGURE 6.2. 1. Remove the seat cushion, if necessary, from the wheelchair. 2. Remove the phillips screws that secure the existing seat upholstery to the seat frame. NOTE: The number of phillips screws will vary depending on the depth of the wheelchair.

  • Page 40: Installing Fabric Clothing Guards

    Mounting Screws Rear Edge of Seat Seat Rail NOTE: Only Hook and Loop style seat positioning strap shown. Auto style seat positioning strap attaches the same way. FIGURE 6.3 Installing/Removing Seat Positioning Strap Installing Fabric Clothing Guards NOTE: For this procedure, refer to FIGURE 6.4. 1.

  • Page 41: Installing Clothing Guards

    Installing Clothing Guards NOTE: For this procedure, refer to FIGURE 6.5. 1. Position the threaded and unthreaded half clamps on inside and outside of the wheelchair frame. NOTE: Make sure the threaded half clamp is on the outside of the wheelchair frame. 2.

  • Page 42: Section 7-Arms

    SECTION 7—ARMS After any adjustments, repair or service and before use, make sure all attachment hardware is tightened securely - otherwise, injury or damage may result. DO NOT attempt to lift or tilt a wheelchair by using any removable (detachable) parts.

  • Page 43: Adjusting Half Arm Height

    Half Arm Locknuts Washers Hex Screw FIGURE 7.1 Installing the Half Arm Adjusting Half Arm Height NOTE: For this procedure, refer to FIGURE 7.2. 1. Remove the half arm from the arm socket. 2. Remove the hex screw, two (2) washers and locknut mounted in the arm socket that determine the half arm height.

  • Page 44: Using/Adjusting Dual Point Arms

    Using/Adjusting Dual Point Arms Make sure the locking mechanism is secured before using the wheelchair. NOTE: For this procedure, refer to FIGURE 7.3. Adjusting Armrest Height 1. Unlock the armrest by flipping the armrest release lever on the top front of the armrest to the UP (HORIZONTAL) position.

  • Page 45: Replacing Dual Point Arm Pad/Clothing Guards

    Replacing Dual Point Arm Pad/Clothing Guards NOTE: For this procedure, refer to FIGURE 7.4. Replacing Arm Pad 1. Remove the phillips screws that secure the arm pad to the armrest assembly. 2. Replace arm pad and securely tighten with the existing phillips screws. Replacing Clothing Guards NOTE: This procedure is for fixed height dual point arms ONLY.

  • Page 46: Removing T-Arms

    Removing T-Arms 1. Press in on the locking lever and lift the T-arm straight up and out of the T-arm socket. NOTE: If the T-arm does not slide up and down in the T-arm socket as desired, adjust the T-arm socket.

  • Page 47: Adjusting T-Arm Width

    • Tighten - Tightening the set screws on the outside T-arm post will make it harder to move the inside T-arm post up and down. • Loosen - Loosening the set screws on the outside T-arm post will make it easier to move the inside T-arm post up and down.

  • Page 48: Adjusting T-Arm Depth

    Adjusting T-Arm Depth NOTE: For this procedure, refer to FIGURE 7.8. 1. Remove the two (2) phillips screws that secure the arm pad to the arm tube. 2. Remove the two (2) socket screws that secure the arm tube to the T-arm post. 3.

  • Page 49: Adjusting T-Arm Sockets

    Adjusting T-Arm Sockets NOTE: For this procedure, refer to FIGURE 7.9. 1. Remove the rear wheels from the wheelchair, if necessary. Refer to Removing/ Installing Rear Wheels on page 51. 2. Loosen, but do not remove the four (4) hex screws and washers that secure T-arm socket to T- arm clamp.

  • Page 50: Adjusting T-Arm Transfer Assists And/Or Side Guards

    Adjusting T-Arm Transfer Assists and/or Side Guards NOTE: For this procedure, refer to FIGURE 7.10. 1. Remove the T-arm from the wheelchair. Refer to Installing/Removing T-Arms on page 45. 2. Remove the two (2) socket screws that secure the side guard to the bottom clamp. NOTE: Adjusting the side guards will directly affect the position of the transfer assist.

  • Page 51: Section 8-Wheels

    SECTION 8—WHEELS After any adjustments, repair or service and before use, make sure all attachment hardware is tightened securely - otherwise, injury or damage may result. Repairing/Replacing Pneumatic Tire/Tube Replacement of a pneumatic tire or tube MUST be performed by a qualified technician.

  • Page 52: Permanent Axles

    Adjusting Quick-Release Axles on page 53 or Adjusting Quad-Release Handles on page 55. NOTE: During contact activities, Invacare recommends inserting quick-release axles with the head end to the inside of the wheelchair to prevent accidental release. Permanent Axles 1.

  • Page 53: Adjusting Quick-Release Axles

    Adjusting Quick-Release Axles NOTE: For this procedure, refer to FIGURE 8.2. 1. Remove rear wheel and quick/quad-release axle from the wheelchair. Refer to Removing/Installing Rear Wheels on page 51. 2. Depress detent pin in the quick-release axle and slide axle through the wheel hub. 3.

  • Page 54: Installing Quad-Release Axles

    Installing Quad-Release Axles NOTE: For this procedure, refer to FIGURE 8.3. 1. Remove rear wheel and the existing quick-release axle from the wheelchair. 2. Remove the existing quick-release axle from the rear wheel hub. 3. Insert the new quad-release axle through the rear wheel hub.

  • Page 55: Adjusting Quad-Release Handles

    Adjusting Quad-Release Handles In and/or Out NOTE: For this procedure, refer to FIGURE 8.4. 1. Remove rear wheel and the quad-release axle from the wheelchair. 2. Loosen the locking screw. 3. Make the following adjustments: A. If the quad-release handle is not releasing the locking pins completely, rotate the quad-release handle approximately one-quarter (1/4) turn clockwise.

  • Page 56: Adjusting Forks

    Adjusting Forks NOTE: For this procedure, refer to FIGURE 8.6. 1. Remove the dust cover from the caster headtube. 2. To properly tighten caster journal system and guard against flutter, perform the following check: A. Tip back the wheelchair to floor. B.

  • Page 57: Section 9-Wheel Locks/Anti- Tippers

    SECTION 9—WHEEL LOCKS/ANTI- TIPPERS After any adjustments, repair or service and before use, make sure all attachment hardware is tightened securely - otherwise, injury or damage may result. Replacing/Adjusting the Wheel Locks NOTE: For this procedure, refer to FIGURE 9.1. NOTE: Before adjusting or replacing the high/undermount wheel locks, ensure that the tires are inflated to the recommended psi on the sidewall of the tire.

  • Page 58: Installing/Adjusting The Anti-Tippers

    Installing/Adjusting the Anti-Tippers Anti-tippers MUST be fully engaged and spring buttons fully protruding out of adjustment holes BEFORE using the wheelchair. Anit-tippers MUST be used at all times. when outdoors on wet, soft ground or on gravel surfaces, anti-tippers may not provide the same level of protection against tip over.

  • Page 59: Installing Amputee Attachments

    Installing Amputee Attachments NOTE: For this procedure, refer to FIGURE 9.4. 1. Remove the rear wheel from the wheelchair. Refer to Removing/Installing Rear Wheels on page 51. 2. Note the position of the axle mounting plate. NOTE: This will maintain the current rear seat to floor height. 3.

  • Page 60: Limited Warranty

    This warranty gives you specific legal rights and you may also have other legal rights which vary from state to state. Invacare warrants its product, except for the seat cushion (which is not warranted), to be free from defects in materials and workmanship for a period of one (1) year from date of purchase.
