Getting Started

3.15 Media Roll Holder Option

The printer may be configured with an optional media holder for media wound on rolls. The
holder is designed to hold media cores of 1.5" or larger and contains media guides intended
to help prevent unnecessary unwinding of media.
Roller holder storage
mounting location when
fanfold media is used.
3-42
Figure 3-19 Rolled Media Holder
Insert the alignment
tabs into the slots
and slide upwards
to position.
The thumbscrews
are then tightened
Thumbscrews
