Getting Started
3.7

Cash Drawer Option

The printer provides a DB15 connector to support the use of 24v cash drawer applications.
The Draw Kick-out solenoid current must be 1 amp or less to avoid current overloads. This
option is only available when using the STL mode.
3.8

AUX Option

The AUX port option or auxiliary port on the printer is for custom application support.
3.9

Niceware Windows Driver

Some applications may choose to use a Windows driver with the printer's instead of creating
a resident LDS driver. The Windows driver typically sends everything over as a graphical
image so the overhead impacting performance is greater than if the resident LDS fonts and
instructions were used.
A WYSIWYG software package group, Nicelabel, has developed a Windows driver for the
Microcom Corporation printer's. The driver has been optimized to use with the Nicelabel
software but may also work for other Windows applications. The driver's may be
downloaded at http://www.nicelabel.com/Downloads/NiceDrivers.
3.9.1

Niceware Windows Driver Setup and Configuration

This section has been created to assist in the installation, setup, and configuration of the
Windows Driver. Any problems or issues with the driver should be reported to Nicelabel
directly.
Follow the steps outlined below to install and configure the Nicelabel Windows drivers:
1. Download and install the Nicelabel Windows driver by executing the "PRNINST.exe" file.
2. Follow the on screen instructions to successfully install the driver or drivers.
3-10
Pin 1 - DR1
Pin 2 - DO
Pin 3 - DR2
Figure 3-3 Cash Drawer Pin-out
428T Operator's Manual - 880037-0141
Chapter 3
