Microcom 428T Operator's Manual page 236

^A ^D COMMAND
X 109 Serial Port Source (volatile)
0 RS-232
1 USB
2 Ethernet
X 110 General Purpose Status Byte
XX 111 Kiosk Cutter Mode: This command enables the non-volatile full and/or partial
cut operation. The ^D112 command is also used with the ^D111 command to
adjust the advance distance to the cutter blades and then retract to the home
position (dot row one).
0 Disable Kiosk Cutter Mode.
1 Enable Kiosk Cutter Mode.
2 Enable partial Kiosk Cutter Mode.
4 Enable full Kiosk Cutter Mode with LTS
XX 112 Kiosk Cutter Advance Distance Command: The valid range is from
0 to 1000 with the recommended distance of 150.
XX 113 Verbose Mode:
0 Disable Verbose Mode.
1 Enable Verbose Mode.
114 GS1 Databar Data Entry Command: The GS1 Databar, formerly known as
the RSS-14, barcode is fully supported by the 324M and 424M printers. There
are 6 different types of GS1 Databar that are supported by the printer:
X 115 Set Cutter Type: Selects the type of cutter installed on the printer.
0 No cutter
1 Guillotine
2 Rotary
X 116 Synchronous Print Mode
0 Exit all sync. modes.
1 Enter single sync. mode.
2 Enter continuous sync. mode.
X 117 Cutter Hold-off: X represents the number of cuts to skip on the first X labels
following a TOF.
X 118 Home Cutter: This command will return the cutter gear to the home or open
position when issued. Only available of the X28 Series of printer's.
XX 119 Display Memory Allocation: This command shows how all of the RAM and
flash memory is being used.
13-16 428T Operator's Manual - 880037-0141
