Microcom 428T Operator's Manual page 167

Chapter 8
^D2
A
Data Matrix
^D3
NOTE: MULTIPLYING THE BARCODE GENERATED.
The barcode generated is based on a single dot width. For the barcode to be visible and to
scan properly, a reasonable multiplier must be used. Typical values for a multiplier are 8-
10. This is accomplished in the LDS1 format above on the line: 1,300,300,1,47,,,,10,10
Height Parameter- 0
This parameter is used to set the height of the Data Matrix symbol. Zero entry will invoke
auto sizing.
Width Parameter- 0
This parameter is used to set the width of the Data Matrix symbol. Zero entry will invoke
auto sizing.
Rotation - 1
0 = 0 degree rotation
1 = 180 degree counter clockwise rotation.
2 = 90 degree counter clockwise rotation.
3 = 270 degree counter clockwise rotation.
Symbol Size
Auto
10 x 10
12 x 12
14 x 14
16 x 16
18 x 18
20 x 20
22 x 22
24 x 24
26 x 26
32 x 32
36 x 36
40 x 40
44 x 44
48 x 48
52 x 52
64 x 64
72 x 72
80 x 80
88 x 88
96 x 96
104 x 104
428T Operator's Manual - 880037-0141
Numeric Alphanumeric
Capacity Capacity
---
6
10
16
24
36
44
60
72
88
124
172
228
288
348
408
560
736
912
1152
1392
1632
Binary Byte
Capacity
---
3
6
10
16
25
31
43
52
64
91
127
169
214
259
304
418
550
682
862
1042
1222
Bar Codes
---
1
3
6
10
16
20
28
34
42
60
84
112
142
172
202
278
366
454
574
694
814
8-15
