The TOF Sensor is
located in front of the
cutter assembly

Figure 3-10 TOF (Top-Of-Form) Sensor

3.13 Media Roll Holder Option

The printer may be configured with an optional media holder for media wound on rolls. The
holder is designed to hold media cores of 1.5" or larger and contains media guides intended
to help prevent unnecessary unwinding of media.

Figure 3-11 Rolled Media Holder
