Chapter 8
8.1.13

Postnet (ZIP+6), TCI 37

Postnet is a numeric-only symbology that is commonly used in postal application to sort
mail. The five-digit zip plus six-digit extension may be used to generate this Postnet (TCI
37) bar code. Example: 12345-123456.
8.1.14

MaxiCode, TCI 38

MaxiCode is a fixed-size, 2-D matrix symbology that is capable of encoding the entire ASCII
character set (0 to 255) and up to 93 characters per symbology. Modes 2 through 6 of the
AIM Internal MaxiCode specification are supported. Modes 0 and 1 are obsolete and are
not supported. The CGN parameter is used to select the desired mode (2-6) of the
symbology.
MaxiCode may encode non-printable characters, and Modes 2 and 3 require certain control
characters for compatibility with transport industry standards. In order to properly specify a
control character in a MaxiCode data string, use the pound symbol ("#") followed by the two
digits Hexadecimal value of the control code. For example, "#01" specifies "Control-A"
(ASCII SOH) and "#1D" specifies "Control-]" (ASCII GS). Enter "##" in order to include an
actual pound symbol in the data string. Refer to Table 15 for the "#" equivalents that may
be used.
The following is the command structure of the ^D71 which is used to load the data for
Maxicode:
^D71<CR>
Mode<CR>
Symbol Number<CR>
Total Number<CR>
Country Code<CR>
Service Code<CR>
Zip Code<CR>
Mode - barcode mode (1 through 6).
Symbol Number - maxicode barcodes can be chained together. This one is
the Nth barcode in a series.
Total Number - Total number of barcodes in the series.
Country Code - Three digits.
Service Code - Three digits.
Zip Code - 9 digits
The data string associated with a MaxiCode field shall be formatted according to the Mode
selected (2-6).
Mode 2
Mode 2 may have either of the following formats:
Format 1
