10.4
Jumpers
The MPCBL0001 contains several jumper posts that allow the user to configure certain options not
configurable through the BIOS Setup Utility. The "Jumper Locations" figure below shows the
placement of the MPCBL0001 jumpers. See
for the function of each jumper.
Note: The MPCBL0001 is shipped pre-configured—jumper positions do not need to be altered.
Figure 27.
Jumper/Connector Locations
Note: Pin 2 is directly beside pin 1 and is marked on the board silkscreen. The back row has odd-
numbered pins and the front row has even-numbered pins.
Technical Product Specification
Order #273817
®
Intel NetStructure
MPCBL0001 High Performance Single Board Computer
J 38
J 37
J 40
1
2
3
J 18
Table 101, "J40 Jumper Assignments" on page 149
J 16
Contents
147
