Table 8 shows the PCI mapping of the component subsystem of the baseboard.
Table 8.

PCI Mapping for Hardware Component Subsystem

Bus
0
0
0
0
0
0
0
2
2
3
4
4
5
7
7
0XFF
NOTE: This table is for MPCBL0001F04 boards. Bus Devices 5 and 7 do not exist for MPCBL0001N04 boards.
Example:
To decode the device and function number from the System Event Log, refer to the following
method.
0144 05/26/04 15:24:42 4023 13 Critical Interrupt 07 PCI PERR 6f [a4 04 08]
•
Event data 1 = a4
Comments:
•
Event data 2 = 04.
Comments: From
•
Event data 3 = 08 = 00001000
Comments:
Event data 3, bit 2:0 is equivalent to 0 which refers to Function number 0. From
PCI parity error was on the interface of the Gigabit Ethernet Controller (Port A).
42
Device Function
0 0 E7501 MCH Bridge
0 1 MCH <-> ICH3
2 0 82870P2 PCI-X Bridge (PMC and Gigabit Ethernet Controller)
3 0 MCH <-> 82870P2 PCI-X Bridge (Fibre Channel Controller)
29 0 USB Controller
31 1 IDE Interface (hard disk drive)
31 3 IPMC Interface
29 0 PCI-X Bridge to Gigabit Ethernet Controller
1 0 PCI-X Bridge to PMC Card
1 0 PMC Card
1 0 Gigabit Ethernet Controller (Port A)
29 1 Gigabit Ethernet Controller (Port A)
29 0 PCI-X Bridge to Fibre Channel Controller
1 0 Fibre Channel Controller (Port A)
1 1 Fibre Channel Controller (Port B)
- - PSB (processor-side bus) Error
FromTable 3 on page 33, event data 1, bit 3:0 is referring to PCI-PERR
Table 3, event data 2, bit 7:0 is referring to Bus number 4.
FromTable 3, event data 3, bit 7:3 is equivalent to 1 which refers to Device number 1.
Hardware Component Subsystem
Technical Product Specification
Table 8 above, the
