Table 33.

Ethernet Controller Port State LED

LED Status (L1 and L5)
Off
Red/Green/Amber
NOTE: Refer to
Front Panel.
3.14.8

Fibre Channel Port State LEDs

The MPCBL0001 SBC supports two Fibre Channel port state LEDs mounted on the front
faceplate. The LEDs are green and yellow. When this LED is lit, it indicates the port state of each
Fibre Channel port. LED states are shown in the table as follows:
Table 34. Fibre Channel Port State LED (DS2, DS3)
Yellow LED Status (Fibre
Channel 1, left)
ON
Flashing
ON
OFF
FLASH
3.14.9

Setting the Default Color for the OOS and Health LEDs

The current default color Health LED in any assertion event is RED. As for the OOS LED, the
default color is also RED if there is a fault or error condition.
With the latest IPMC Firmware 1.17, the user has the ability to set the default color to AMBER due
to geographical requirements. This default LED color will stay persistent upon IPMC reset.
The PICMG SetFRULedState command used with Function code 0xFC will now persistently save
the supplied explicit color and make it the new Local Control "Asserted" state color. This only
works with valid colors (not 0x0e or 0x0f).
So, for example, to set the default "Asserted" color of the Health LED from RED to AMBER, the
following IPMI command should be issued:
NetFn:
Cmd:
Data 1: 0x00
Data 2: 0x00
Data 3: 0x02
Data 4: 0xFC
Data 5: 0x00
Data 6: 0x04
After this command is executed, the Health LED will illuminate as AMBER instead of RED on an
unhealthy event. The "Unasserted" color will remain GREEN.
Technical Product Specification
Order #273817
®
Intel NetStructure MPCBL0001 High Performance Single Board Computer
No Status
Active status of user-defined function
Figure 14 and Figure 15
Green LED Status (Fibre
Channel 2, right)
ON
OFF
OFF
ON
FLASH
0x2C PICMG 3.0 Extension
0x07 SetFRULedState command
PICMG Identifier
FRU Device ID
LED ID (LED 2 = Health LED)
LED Function (Restore Local Control)
On-Duration (ignored)
LED Color (4 = Amber)
Meaning
for LED (L1 and L5) placement on the
Meaning
Power On
Loss-of-Sync
Signal Acquired
On-Line
F/W Error
Contents
69
