Intel NetStructure MPCBL0001 High Performance Single Board Computer
Contents

BIOS Setup

8.1

Introduction

The BIOS Setup program can be used to view and change the BIOS settings for the computer. The
BIOS Setup program is accessed by pressing the <F2> key after the Power-On Self-Test (POST)
begins and before the operating system boot begins.
features.
Table 64.

BIOS Setup Program Menu Bar

Main
Allocates resources
for hardware
components
Table 65
Table 65.

BIOS Setup Program Function Keys

BIOS Setup Program
Function Key
<← > or <→ >
<↑ > or <↓ >
<Tab>
<Enter>
<F9>
<F10>
<Esc>
8.2

Main Menu

To access this menu, select Main on the menu bar at the top of the screen.
Table 66
used for configuring the system date and system time.
116
Advanced
Configures advanced
features available
through the chipset
lists the function keys available for menu screens.
Selects a different menu screen (moves the cursor left or right).
Selects an item (moves the cursor up or down).
Selects a field (not implemented).
Executes command or selects the submenu.
Loads the default configuration values for the current menu.
Saves the current values and exits the BIOS Setup program.
Exits the menu.
Main Advanced
describes the Main menu. This menu reports processor and memory information and is
Table 64 lists the BIOS Setup program menu
Boot Security
Selects boot Sets passwords
options and power and security
supply controls features
Description
Boot Security
Technical Product Specification
8
Exit
Saves or discards
changes to Setup
program options
Exit
Order #273817
