Options - Icom iC-M91D Instruction Manual

14
SPECIFICATIONS AND OPTIONS

Options

■
• BP-275 Li-ion
battery pack
Battery pack Voltage
BP-275
*
The operating periods are calculated under the following
conditions; TX : RX : Standby = 5 : 5 : 90
• BC-204
regular charger
Used for regular charging of battery pack.
(Charging time: approximately 9 hours)
• BC-205
rapid charger
For rapid charging of battery pack.
(Charging time: approximately 2.5 hours)
• BC-197
rapid charger
For rapid charging of 6 battery packs.
(Charging time: approximately 2.5 hours)
• OPC-515L/OPC-656
For charging of the battery packs using a 12 V DC power source
instead of the AC adapter.
(OPC-515L for BC-204 and BC-205 : OPC-656 for BC-197)
• HM-167
speaker microphone
Full sized waterproof speaker-microphone including alligator type
clip to attach to your shirt or collar.
91
Capacity Battery life*
1500 mAh (min.)
7.4 V
1590 mAh (typ.)
+ BC-147S
ac adapter
+ BC-123S
ac adapter
+ BC-157S
ac adapter
dc power cable
• FA-SC59V
• MB-109
belt clip
• MB-96F
leather belt hanger
8 hrs. • CP-23L/CP-25
For charging with the BC-204 or BC-205 charger through a 12 V
cigarette lighter socket.
(CP-25 for BC-204 : CP-23L for BC-205)
NOTE:
The CP-23L is equipped with a 4 A fuse and the CP-25 with a
1 A fuse. If the fuses blow, replace them with new rated fuses.
DO NOT use fuses with amp ratings other than the ratings writ-
ten above.
Approved Icom optional equipment is designed for optimal perfor-
mance when used with an Icom transceiver. Icom is not responsible
for the destruction or damage to an Icom transceiver in the event
the Icom transceiver is used with equipment that is not manufac-
tured or approved by Icom.
antenna
cigarette lighter cable
Fuse
CP-23L: (4 A /125 V)
CP-25 : (1 A /250 V)
