HARDWARE CONTENTS

Part
Description Quantity
AA Cam Dowel
Cam Lock
BB
Wall Anchor
CC
ST4 Screw
DD
1 -3/16 in.
ST5 Screw
EE
2- 3/8 in.
WARNINGS AND CAUTIONS
WARNING
When tightening screws, do not over tighten, this may cause threads to strip. We recommend using a
hand-held screwdriver rather than a power screwdriver.
Do not force screws into holes.
CAUTION
For corner installations(optional); if baseboards are installed where the fireplace is intended to be
displayed, then the fireplace will not fit flush against the wall. For a proper flush fit, you may need to remove
part of the baseboard mold if necessary.
PREPARATION
Before beginning assembly of product, make sure all hardware contents parts are present. Compare parts with
package contents list and diagram on page 4. If any part is missing or damaged, do not attempt to assemble the
product. Contact customer service for replacement parts.
Estimated Assembly Time: 60 minutes
Tools Required for Assembly: Philips Screwdriver, Flathead Screwdriver, Drill, and Tape Measure.
(Shown to size)
16
16
BB
2
8
2
Part
Description
ST4 Screw
FF
5/8 in.
Connector
GG
Bracket
HH
White Key
ST4 Screw
II
1 -9/16 in.
4
Quantity
(Shown to size)
18
3
1
8
