NO TRAY XX
If feed from the T2/T3, the T1/T2 in the paper path is not installed.
<User Check>
- Install the T1 or T2.
Step
Harness connection failure of PE
EG sensor ASSY of T1 or T2
1
2 LT PCB ASSY failure
3 Connector 55533-1219
PE EG sensor ASSY of T1 or T2
4
failure
5 Main PCB ASSY failure
PRINT OVERRUN
Print date capacity is flooded the memory capacity of machine.
<User Check>
- Reduce the complexity of data or reduce the print resolution.
- Add on the DIMM.
REPLACE DRUM
Drum unit is the time for replacement.
Replace the drum unit.
REPLACE FUSER
Fuser unit is the time for replacement.
Step
Fuser unit is the time for
1 replacement
REPLACE LASER
Laser unit is the time for replacement.
Step
Laser unit is the time for
1 replacement
Cause
Check the sensor performance following
the procedure in
in 1.3 Service Mode in Chapter
If any problem occurs, check the harness
connection of the PE EG sensor ASSY.
Replace the LT PCB ASSY.
Replace the connector 55533-1219.
Replace the PE EG sensor ASSY of the T1
or T2.
Replace the main PCB ASSY.
Cause
Replace the fuser unit and reset the
counter. (Refer to
Menu" in Chapter
Cause
Replace the laser unit and reset the
counter. (Refer to
Menu" in Chapter
3-23
Remedy
"Factory Inspection Mode"
7.
Remedy
"2.2 Reset Parts Life
7.)
Remedy
"2.2 Reset Parts Life
7.)
