8.19 Toner Sensor PCB

(1) Remove the Toner sensor PCB unit ASSY from the Frame L.
rame L
(2) Remove the PT sensor holder from the Toner sensor PCB ASSY.
Fig. 5-77
Toner sensor PCB ASSY
Fig. 5-78
5-62
Toner sensor PCB unit ASSY
Hooks
PT sensor holder
Hooks
Confidential
