9
D1
B9
Remove M5x10 bolts (D1) from drip tray handle (B12). Attach the drip tray handle
onto drip tray (B9) using the bolts. Slide the drip tray underneath barbecue body
from rear.
10
Attach the warming rack (B14) to the
hood as shown.
B12
B9
(Rear view of the barbecue trolley.)
C6
Attach the screen (C6) to the front left/right
legs as shown.
9
