combustible surface. Keep this barbecue away
from any flammable materials!
G2. Precautions
Do not obstruct any ventilation openings in the
barbecue body. Position the gas supply bottle
on level ground next to the barbecue and safely
away from any source of heat. Should you
need to change the gas bottle, confirm that the
barbecue is switched off, and that there are no
sources of ignition (cigarettes, open flame,
sparks, etc.) near before proceeding. Inspect
the gas hose to ensure it is free of any twisting
or tension. The hose should hang freely with no
bends, folds, or kinks that could obstruct free
flow of gas. Apart from the connection point, no
part of the hose should touch any hot barbecue
parts. Always inspect the hose for cuts, cracks,
or excessive wear before use. If the hose is
damaged, it must be replaced with hose
suitable for use with LPG and meet the national
standards for the country of use. The length of
the hose shall not exceed 1.5m. N.B.-The date
on U.K. orange hose
manufacture, not the expiry date.
G3. Fixing the Regulator to the Gas Bottle
Confirm all barbecue control knobs are in the
off position. Connect the regulator to the gas
bottle according to your regulator and bottle
dealer's instructions.
G4. Leak Testing (To be performed in a
well-ventilated area.)
Confirm all control knobs are in the off position.
Detach the barbecue control panel located
across the front of the barbecue body by pulling
off the control knobs and removing the control
panel retaining screws. Open the gas control
valve on the bottle or regulator. Check for leaks
by brushing a solution of ½ water and ½ soap
over all gas system joints, including all valve
connections, hose connections and regulator
connections. NEVER USE AN OPEN FLAME
to test for leaks at anytime. If bubbles form over
any of the joints, there is a leak. Turn off the
gas supply and retighten all joints. Repeat test.
If bubbles form again, do not use the barbecue.
Please contact your local dealer for assistance.
Leak test annually, and whenever the gas
bottle is removed or replaced.
H. Operation
H1. nWarnings
n Before proceeding, make certain that you
is the date of
12
understand the
INFORMATION section of this manual.
n This barbecue is not designed to be used
with more than 50% of the cooking area as
a solid plate. Full coverage of plates will
cause excessive build-up of heat and
damage the barbecue.
H2. Preparation Before Cooking
Line the drip tray with aluminium foil and fill the
drip tray with dry sand. This will absorb excess
cooking fat and make cleaning easier. To
prevent foods from sticking to the porcelain,
please use a long handled brush to apply a
light coat of cooking or vegetable oil before
each barbecuing session.
H3. Lighting the Barbecue Using
Integra-Spark Integrated Ignition System
Open the roasting hood of your barbecue
x
before lighting.
Open the gas control valve on the gas
x
bottle or regulator.
Push the control knob of the burner you
x
wish to light and turn it anti-clockwise until
you feel resistance to the turning. Pause 4
seconds, then continue turning the control
knob until a click is heard and the burner is
lit. If burner does not light, turn off the gas
by pushing and holding in the control knob
in at the "High" position and turning to "Off".
The lighting sequence can then be
repeated 4-5 times until the burner is lit.
Ignite any of the remaining burners in any
order, as needed. Confirm each burner is
alight before igniting another burner. If any
burner fails to ignite after following above
procedure, turn all the knobs to the off
position. Close the gas valve on the gas
bottle. Wait five minutes. Reattempt all of
the above steps. If the barbecue still fails to
light, please refer to the manual ignition
instructions below.
After ignition, turn the burners to the high
x
position for 3-5 minutes in order to pre heat
the barbecue. This should be done before
each cooking session. When pre heating is
complete, cooking can begin, taking extra
care if burners are left in the high position.
H4. Manual lighting instructions
Insert lit match through the leftmost match-
x
lighting hole on the underside of the control
panel and place near leftmost burner
porthole.
Push and turn the leftmost control knob
x
IMPORTANT
the
