1.2 Main Features

y Four 10/100Mbps Auto-Negotiation RJ45 LAN ports (Auto MDI/MDIX), one RJ11 port.
y Provides external splitter.
y Adopts Advanced DMT modulation and demodulation technology.
y Supports bridge mode and Router function.
y Multi-user sharing a high-speed Internet connection.
y Downstream data rates up to 24Mbps, upstream data rates up to 3.5Mbps（With Annex M enabled（.
y Supports long transfers, the max line length can reach to 6.5Km.
y Supports remote configuration and management through SNMP and CWMP.
y Supports PPPoE, it allows connecting the internet on demand and disconnecting from the Internet when idle.
y Provides reliable ESD and surge-protect function with quick response semi-conductive surge protection circuit.
y High speed and asymmetrical data transmit mode, provides safe and exclusive bandwidth.
y Supports All ADSL industrial standards.
y Compatible with all mainstream DSLAM (CO).
y Provides integrated access of internet and route function which face to SOHO user.
y Real-time Configuration and device monitoring.
y Supports Multiple PVC (Permanent Virtual Circuit).
y Built-in DHCP server.
y Built-in firewall, supporting IP/MAC filter, Application filter and URL filter.
y Supports Virtual Server, DMZ host and IP Address Mapping.
y Supports Dynamic DNS, UPnP and Static Routing.
y Supports system log and flow Statistics.
y Provides WPA-PSK/WPA2-PSK data security, TKIP/AES encryption security.
y Provides 64/128-bit WEP encryption security and wireless LAN ACL (Access Control List).

1.3 Factory Defaults

Item
Common Default Settings
Username
Password
IP Address
Subnet Mask
Wireless
SSID
Wireless Security
Security Type
Encryption
WPA KEY
DHCP Server
Default Value
admin
admin
192.168.1.1
255.255.255.0
KRAUN_XXXXXX
KRAUN_the last 6 characters of MAC address (example KRAUN_123456)
Enable
WPA-PSK/WPA2-PSK
TKIP+AES
KRAUN_KN.3N
Enable
