Kraun ADSL2/2+ Wireless-N Router User Manual page 25

y Starting IP Address: Enter the starting IP address for the DHCP server's IP assignment. Because the default IP
address for the Router is 192.168.1.1, the default Start IP Address is 192.168.1.100, and the Start IP Address
must be 192.168.1.100 or greater, but smaller than 192.168.1.254.
y IP Pool Count: The max user pool size.
y Lease Time: The length of time for the IP lease. After the dynamic IP address has expired, the user will be
automatically assigned a new dynamic IP address. The default is 259200 seconds.
y Physical Ports: Specify the Physical Ports of the DHCP client.
y DNS Relay: If you want to disable this feature, you just need to set both Primary and secondary DNS IP to
0.0.0.0. If you want to use DNS relay, you can setup DNS server IP to 192.168.1.1 on their Computer. If not, the
device will perform as no DNS relay.
y Primary DNS Server: Type in your preferred DNS server.
y Secondary DNS Server: Type in your preferred DNS server.
y Current Pool Summary: Click the button, then you can view the IP addresses that the DHCP Server gives out.
NOTE: If Use Auto Discovered DNS Server Only is selected in DNS Relay, this router will accept the first re-
ceived DNS assignment from one of the PPPoA, PPPoE or MER/DHCP enabled PVC(s) during the connec-
tion establishment. If Use User Discovered DNS Server Only is selected in DNS Relay, it is necessary for
you to enter the primary and optional secondary DNS server IP addresses. After type in the address, click
SAVE button to save it and invoke it.
y DHCP Relay: Select Relay, then you will see the next screen (shown in Figure 4-13), and the Router will work
as a DHCP Relay. A DHCP relay is a computer that forwards DHCP data between computers that request IP
addresses and the DHCP server that assigns the addresses. Each of the device's interfaces can be configured
as a DHCP relay. If it is enabled, the DHCP requests from local PCs will forward to the DHCP server runs on WAN
side. To have this function working properly, please run on router mode only, disable the DHCP server on the
LAN port, and make sure the routing table has the correct routing entry.
y DHCP Server IP for Relay Agent: Enter the DHCP server IP Address runs on WAN side.
NOTE: If you select Disabled, the DHCP function will not take effect.
Figure 4-12
Figure 4-13
