Bridge Mode - Kraun ADSL2/2+ Wireless-N Router User Manual

y Static/Dynamic IP Address: For PPPoE/PPPoA connection, you need to specify the public IP address for this
ADSL Router. The IP address can be either dynamically (via DHCP) or given IP address provided by your ISP. For
Static IP, you need to specify the IP address, Subnet Mask and Gateway IP address.
y Default Route: You should select Yes to configure the PVC as the default gateway to internet from this device.
y MAC Spoofing: Enable the MAC Spoofing, and enter a MAC address to configure the WAN port. It makes your
inside network appear as a device with this MAC address to the outside world.

4) Bridge Mode

If you select this type of connection, the modem can be configured to act as a bridging device between your
LAN and your ISP. Bridges are devices that enable two or more networks to communicate as if they are two seg-
ments of the same physical LAN.
NOTE: After you finish the Internet configuration, please click SAVE to make the settings take effect.
Figure 4-10
