y VLAN Index: Select the VLAN index for this VC. You can specify 8 groups in maximum.
y VLAN ID: This indicates the VLAN group.
y ATM VCs: Select the ATM VCs as members of VLAN, and if you leave the Tagged blank, the tag in frames will
be deleted when transmitted from the VC.
y Ethernet: Select the Ethernet port as a member of VLAN.
y Wireless LAN: Select the wireless LAN port as a member of VLAN, and if you leave the Tagged blank, the tag
in frames will be deleted when transmitted from the port.
y VLAN Group Summary: This displays the information about the VLAN Groups.

4.4.6 ADSL

Choose "Advanced SetupADSL", you can select the ADSL Type and ADSL Mode in the next screen. The ADSL
feature can be selected when you meet the physical connection problem. Please check the proper settings with
your Internet service provider.
y ADSL Mode: Select the ADSL operation mode which your ADSL connection uses.
y ADSL Type: Select the ADSL operation type which your ADSL connection uses.

4.5 Access Management

Choose "Access Management", you can see the next submenus:
Click any of them, and you will be able to configure the corresponding function.
Figure 4-36
Figure 4-37
