During A Call; Adjust The Volume During A Call; Open Contacts During The Call; Turn The Microphone On/Off During A Call - ASCOM d41 DECT User Manual

User Manual
Ascom d41 DECT Handset
6.3

During a Call

Note: Some of these functions are system dependent. The parameters are set up in the
Portable Device Manager (PDM), see Configuration Manual, Ascom d41 DECT Handset,
TD 92641EN, and Installation and Operational Manual, Portable Device Manager (PDM),
Windows version, TD 92325EN.
If the handset is configured via PDM, it is possible to call a predefined emergency number
while the handset/keypad is locked. When calling from a locked handset, it is only possible
to access the Microphone on/off function by pressing the soft key "More". However, the
entire In Call menu is accessible when calling from a handset with locked keypad.
6.3.1

Adjust the Volume during a Call

On the navigation key, press
The handset will now store and keep the new volume level.
6.3.2

Open Contacts during the Call

1 Press the "More" Soft key during the call.
2 Select "Contacts".
3 Press "Select".
4 Select "Call contact" for searching a local or company phonebook contact, or
select "Central phonebook" for searching a central phonebook contact.
5 Press "Select".
6 Select or search contact.
Note: It is possible to call the selected contact by pressing "Call". When calling the
contact, the first call will be put on hold. See also
Conversation.
6.3.3

Turn the Microphone on/off during a Call

1 Press the "More" Soft key during the call
2 Select "Microphone off"
3 Press "Select".
The icon indicates a silenced microphone. This means that the other part in an
ongoing call cannot hear you. To turn the microphone back on, do as follows:
1 Press the "More" Soft key during the call.
2 Select "Microphone on".
3 Press "Select".
It is also possible to turn the microphone off/on by a long press on
6.3.4

Start a New Call during Conversation

1 Press the "More" Soft key during the call.
2 Select "New Call"
3 Press "Select".
4 Enter number, or press
1.Visible if defined in the PDM.
21 June 2012 / Ver. G
and to increase and decrease the volume, respectively.
1
.
to access the phonebook.
6.3.4 Start a New Call during
.
TD 92582EN
23
