"Full battery" icon is displayed in upper right corner.
The "Low battery" icon is displayed when the battery has 10% or less
remaining capacity left. In addition; a warning signal sounds every
minute, the LED flashing orange, and the dialog window "Battery low.
Charge now." appears.
The "Empty battery" icon is flashing when the battery has 5% or less
remaining capacity left. In addition; a warning signal sounds every
second, the LED flashing red, and the dialog window "Battery empty.
Shutting down." appears.
"Sound off" icon is displayed when the Sound off key is pressed, and
when the handset, with the in charger function "Sound off" enabled, is
placed in a charger.
"Microphone off" icon indicates a silenced microphone. It is displayed
after a long press on the Sound off key during a call.
"Loudspeaking" icon is displayed in the soft key bar during a call.
Pressing this icon will turn on the loudspeaker.
"Loudspeaking off" icon is displayed after the soft key for Loudspeaking
icon has been pressed. Pressing this icon will turn off the loudspeaker.
"Key lock" icon indicates a locked keypad.
"Locked entry" icon indicates that the contact cannot be edited or
deleted by the user.
"Phone lock" icon indicates a locked handset.
"Headset" icon indicates that a corded headset is connected to the
handset.
"Outgoing call" icon is added to all outgoing calls in the call list.
"Incoming call" icon is added to all answered calls in the call list.
"Missed call" icon is added to all missed calls in the call list.
"Missed call" icon is added in the status bar. This icon remains until the
"Call list" is opened.
"PDM/IMS3 communication" icon is visible when handset is communi-
cating with PDM/IMS3 via advanced charger.
"Voice mail" icon indicates that new voice mail has been received.
