system features learn routine

The System Features Learn Routine dictates how the unit operates. Due to the number of features, they have been
divided into three menus. It is possible to access and change any of the feature settings using the Valet/program
switch, however, this process can be greatly simplified by using the optional DEI Bitwriter (P/N 998T) or Personal
Computer Interface, P/N 996T. Any of the settings can be changed and then assigned to a particular transmit-
ter, up to four, a feature called Owner Recognition. Each time that particular transmitter is used to disarm the
system, the assigned feature settings will be recalled. Owner Recognition is only possible when programming the
unit with the 996T or the 998T DEI Bitwriter.
Using the optional DEI Bitwriter or PC Interface, the learn routine may be locked. Make sure the learn routine is
unlocked before programming features. If the siren generates one long chirp when attempting to program the
unit, the learn routine is locked and must be unlocked using the DEI Bitwriter or PC before proceeding.
TO ENTER THE SYSTEM FEATURES LEARN ROUTINE
1.
2.
3.
4.
5.
24
Open a door. (The H1/5 GREEN wire or the H1/7 VIOLET wire must already be connected.)
Turn the ignition on and then back off. (The YELLOW wire, H1/9 must already be connected.)
Select a Menu. Press and HOLD the Valet/program switch. (The Valet/program switch must
be plugged into the blue port.) After 3 seconds, the siren will chirp once indicating entry
into Feature Menu 1. If this is the menu you want to access, release the button and advance
to Step 4. If the button is not released, you will jump to the next Feature Menu and the
siren will chirp twice. There are three possible feature menus. Once you have selected the
desired feature menu, release the Valet/program switch.
Select a Feature. Press and release the Valet/program switch the number of times corre-
sponding to the feature you wish to change. For example, to access the third feature, press
and release the Valet/program switch three times. Then press it once more and HOLD it.
The siren will chirp the number of times corresponding to the feature you have accessed.
Program the Feature. While HOLDING the Valet/program switch, you can toggle the
feature on and off using the remote transmitter. Pressing Button I will select the one chirp
or default setting. Pressing Button II will select the two chirp setting.
