shock sensor, 4-pin plug

RED, BLACK
These wires supply constant power and ground to the shock sensor.
BLUE, GREEN
These wires are multiplex inputs. They are both connected to the same zones. If an input of less than 0.8 seconds
is supplied to either wire, the Warn Away response will occur and the LED will report Zone 5. An input longer than
0.8 seconds to either wire will initiate the triggered sequence and report Zone 2. The plug-in shock sensor has
been designed to provide a 0.8 second pulse on the green wire and a 1 second pulse on the blue wire.

programmer interface, 3-pin plug

The black three pin port is provided for programming of the unit. When using the optional DEI Bitwriter (P/N
998T) or PC Interface module, P/N 996T, it is possible to configure any and all of the programmable functions.
The 996T interface requires using an IBM compatible personal computer. For more information please refer to the
guide packaged with the 996T.

voice module interface, 3-pin plug

Many functions of this unit can be vocalized using the optional voice module, P/N 516M. The three pin tan port
is used to link the voice processor to the main unit. When using the optional voice processor, program the main
unit for voice and siren (Feature 2-1 in the Feature Menus section of this guide). For more information, refer to
the guide packaged with the 516M.
