relay harness (H2), 8-pin connector

relay harness wiring diagram

___
RED/WHITE
H2/A
___
BLACK/WHITE
H2/B
___
WHITE/BLACK
H2/C
___
GREEN/BLACK
H2/D
___
H2/E VIOLET/BLACK*
___
H2/F BROWN/BLACK
___
H2/G
BLUE/BLACK
___
H2/H
VIOLET*
*NOTE: VIOLET and VIOLET/BLACK are common at fuse holder.

relay harness wiring guide

H2/A RED/WHITE INPUT TO ON-BOARD CHANNEL 2 (TRUNK RELEASE) RELAY
This wire is used to supply voltage to the H1/12 output. If you want a positive output on the H1/12 wire,
connect this wire to (+)12V. Always fuse appropriately. If a negative output is desired, connect the H2/A
red/white wire to chassis ground.
H2/B BLACK/WHITE INPUT TO DOMELIGHT SUPERVISION RELAY
This wire determines what the output polarity of the H1/4 wire will be. If the door pin circuit is negative, connect
to chassis ground. If the doorpin circuit is positive, connect to a fused 12V source.
H2/C, H2/D, H2/E, H2/F, H2/G, AND H2/H POWER DOOR LOCK WIRES
This security system has door lock relays on-board the control module, and can directly interface with most
electric power door lock systems drawing 30 amps or less. It can also drive aftermarket actuators directly.
Some vehicles require that an aftermarket actuator be added to the driver's door to allow system control. (See
Type D wiring.)
8
CHANNEL 2 RELAY INPUT #87
DOMELIGHT SUPERVISION RELAY INPUT #87
LOCK #87A NORMALLY CLOSED
LOCK #30 COMMON (OUTPUT)
LOCK #87 NORMALLY OPEN (INPUT)
UNLOCK #87A NORMALLY CLOSED
UNLOCK #30 COMMON (OUTPUT)
UNLOCK #87 NORMALLY OPEN (INPUT)
