system features menus

The default settings are indicated in bold type. Features that have additional settings that can be programmed
using the Bitwriter are indicated with an asterisk (*).

Feature Menu 1: Basic Features

FEATURE DEFAULT ONE-CHIRP SETTINGS
NUMBER (PRESS TRANSMITTER BUTTON I)
1-1 Active arming
1-2 Audible arm/disarm confirmation on
1-3 Ignition controlled door locks on*
1-4 Active locking
1-5 Panic with ignition on
1-6 0.8-second door lock pulses
1-7 Forced passive arming on
1-8 Automatic engine disable on
1-9 Armed When Driving (AWD) on
1-10 Code Hopping on

Feature Menu 2: Advanced Features

FEATURE DEFAULT ONE-CHIRP SETTINGS
NUMBER (PRESS TRANSMITTER BUTTON I)
Siren only
2-1
30-second siren duration*
2-2
Nuisance Prevention Circuitry on
2-3
Progressive door trigger
2-4
Ghost Switch input 2 pulses
2-5
Standard disarm mode
2-6
Ignition controlled domelight on
2-7
Ignition lock off if door open
2-8
Panic mode on
2-9
Door sensor bypass chirp on
2-10
26
TWO-CHIRP SETTINGS
(PRESS TRANSMITTER BUTTON II)
Passive arming
Audible arm/disarm confirmation off
Ignition controlled door locks off
Passive locking
No panic with ignition on
3.5-second door lock pulses
Forced passive arming off
Automatic engine disable off
Vehicle Recovery System (VRS) on
Code Hopping off
TWO-CHIRP SETTINGS
(PRESS TRANSMITTER BUTTON II)
Voice module and siren
60-second siren duration
Nuisance Prevention Circuitry off
Instant door trigger
Ghost Switch input 1-5 pulses
Ghost Switch only disarm mode
Ignition controlled domelight off
Ignition lock on if door open
Panic mode off
Door sensor bypass chirp off
