auxiliary output harness (H3), 11-pin connector

auxiliary output harness wiring diagram

___
GREEN/BROWN
H3/1
___
BROWN/BLACK
H3/2
___
PURPLE/BLACK
H3/3
___
GRAY/BLACK
H3/4
___
WHITE/BLACK
H3/5
___
H3/6 BROWN
___
H3/7 BLUE
___
H3/8 GREEN
___
H3/9
ORANGE/BLACK
___
H3/10
BLACK/WHITE
___
H3/11
PINK/BLACK

auxiliary output harness wiring guide

H3/1 GREEN/BROWN (-) MULTIPLEX SENSOR INPUT
This multiplexed input is capable of triggering either the Warn Away response or the triggered sequence. Inputs
that are shorter than 0.8 seconds will only trigger Warn Away. The first stage of DEI dual stage sensors supplies
this type of pulse. Inputs that are longer than 0.8 seconds will trigger the full alarm cycle. The full trigger will
report on Zone 4 and the Warn Away will report on Zone 6.
H3/2 BROWN/BLACK (-) SENSOR SHUNT INPUT
When ground is applied to this wire, all sensors will be bypassed. The only inputs capable of triggering the system
while this wire is grounded are the door trigger and the ignition. After ground is removed, the system will begin
responding to sensors after 5 seconds. During the 5 second recovery period, an input from any sensor will reset
the 5-second recovery timer. This wire can be used to bypass sensors for remote starting, window roll up, etc.
PROGRAMMABLE OUTPUTS
The outputs for Channels 4 (H3/3), 5 (H3/4) and 6 (H3/5) are programmable. Each of the outputs supplies
200 mA of current and cannot directly drive high current circuits. Selectability allows the installer to configure
the system for a wide range of applications. The four types of outputs that are available are:
18
(-) SENSOR INPUT MULTIPLEX ZONES 4 AND 6
(-) SENSOR SHUNT INPUT
(-) 200 mA CHANNEL 4 OUTPUT
(-) 200 mA CHANNEL 5 OUTPUT
(-) 200 mA CHANNEL 6 OUTPUT
(-) 200 mA HORN HONK OUTPUT
(-) 200 mA SECOND UNLOCK/CHANNEL 7
(-) 200 mA FACTORY SECURITY DISARM OUTPUT
(+) GHOST SWITCH INPUT
IGNITION LOCK SAFETY INPUT
(-) DELAYED ACCESSORY OUTPUT
