Feature Menu 3: Auxiliary Channel Outputs

FEATURE DEFAULT ONE-CHIRP SETTINGS
NUMBER (PRESS TRANSMITTER BUTTON I)
3-1 Channel 3 validity
3-2 Channel 4 validity
3-3 Channel 5 validity
3-4 Channel 6 validity
3-5 Channel 6 15-second timed
3-6 Channel 7 second unlock
3-7 Double pulse unlock off
3-8 Horn output flashing
3-9 Disarm with Channel 2 ON
3-10 Ground When Armed (GWA) in Valet mode ON

feature descriptions

The features of the system are described below. Features that have additional settings that can be selected only
when programming with the PC interface or Bitwriter are indicated by the following icon:

feature menu 1: basic features

1-1 ACTIVE/PASSIVE ARMING: When active arming is selected, the system will only arm when the transmitter is
used. When set to passive, the system will arm automatically 30 seconds after the last door is closed. To alert
the consumer of passive arming, the siren will chirp 20 seconds after the door is closed. This provides the con-
sumer with an audible warning prior to the system actually arming. At the 30 second mark, the system will arm,
but the siren will not chirp.
1-2 AUDIBLE ARM/DISARM CONFIRMATION ON/OFF: This feature controls the chirps or voice messages (if using
the 516M) that confirm the arming and disarming of the system.
© 2001 Directed Electronics, Inc. Vista, CA
TWO-CHIRP SETTINGS
(PRESS TRANSMITTER BUTTON II)
Channel 3: latched/latched, reset with
ignition/timed 30/60/90
Channel 4: latched/latched, reset with
ignition/timed 30/60/90
Channel 5: latched/latched, reset with
ignition/timed 30/60/90
Channel 6: latched/latched, reset with
ignition/timed (see Feature 3-5)
Channel 6: 5/10/20/25/30-second timed*
Channel 7: standard channel
Double pulse unlock on
Horn output constant
Disarm with Channel 2 OFF
GWA in Valet mode OFF
