Shinybow USA SB-5688AK Instruction Manual

8x8 hdmi matrix switch with auxiliary audio i/o
Hide thumbs Also See for SB-5688AK:
Table of Contents

Advertisement

Quick Links

Download this manual
INSTRUCTION MANUAL
M ULT I MEDI A AU DIO A N D VI SU A L
MODEL : SB-5688AK
8x8 HDMI Matrix Switch with Auxiliary Audio I/O
8x8 HDMI Matrix Routing Switch w/ Full EDID Management/Learning w/ Auxiliary
Audio Input/Output 4k2k Capable
HDMI-AUDIO MATRIX SWITCHER SERIES
Thank you for purchasing the SB-5688AK HDMI Matrix Switch with Auxiliary. You will fi nd this unit easy to install
and highly reliable but it is essential that you read this manual thoroughly before attempting to use 8x8 HDMI
Matrix switcher.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SB-5688AK and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Shinybow USA SB-5688AK

Summary of Contents for Shinybow USA SB-5688AK

  • Page 1 HDMI-AUDIO MATRIX SWITCHER SERIES Thank you for purchasing the SB-5688AK HDMI Matrix Switch with Auxiliary. You will fi nd this unit easy to install and highly reliable but it is essential that you read this manual thoroughly before attempting to use 8x8 HDMI...

  • Page 2: Safety Information

    SAFETY INFORMATION To ensure the best results from this product, please read this manual and all other documentation before operating your equipment. Retain all documentation for future reference. Follow all instructions printed on unit chassis for proper operation. To reduce the risk of fi re, do not spill water or other liquids into or on the unit, or operate the unit while standing in liquid. Make sure power outlets conform to the power requirements listed on the back of the unit.

  • Page 3: Table Of Contents

    6.75 Gbps. Supports UXGA/WUXGA/DVI 1920x1200 resolution to any HD displays. The SB-5688AK has 1x HDMI and Auxiliary We reserve the right to make improvements to this document and/ Audio(analog stereo audio) connector for Input, effectively making or product at any time and without notice.

  • Page 4: Package Contents

    PACKAGE CONTENTS PACKAGE CONTENTS Check that you have the following components; • SB-5688AK Matrix Switcher • RS-232 V2.0 Protocol Instructions • Ethernet V2.0 Protocol Instructions • Master wireless IR Remote Control (SW-HD88AK) • 19 inch Ear mount bracket (Part # 1U-440L) •...

  • Page 5: Features

    FEATURES FEATURES • (8)x HDMI with Auxiliary Audio (Analog Audio) source devices matrix switched to • (8)x HDMI with S/PDIF output destinations. • HDMI digital Video w/embedded HDCP, DVI format and CEC/HDCP 2.0 compliant • Worldwide control EDID modes for HDMI full 4K2K (24/30 Hz) HD Video resolutions. •...

  • Page 6: Specifications

    SPECIFICATIONS SPECIFICATIONS • Type of HDMI Switcher: 8x inputs To 8x Outputs HDMI Matrix Switch with Audio and Extension • HDMI Support: HDMI 4K2K, 1080p-@60Hz, H36-bit Deep color, 3D of HDMI V1.4 formats • HDCP / CEC Support: HDCP 2.0 Compliant, CEC Compliant •...

  • Page 7: Front Panel

    FRONT PANEL FRONT PANEL 1. POWER ON SWITCH The power switch turns the unit on and off. The LCM will illuminate blue to indicate the switcher is ON and receiving power. The switcher will remember the last setting during a power cycle. When power is removed and resorted, the last confi guration will be evoked. 2.

  • Page 8: Front Panel- Arc

    FRONT PANEL- ARC FRONT PANEL 9. FUNCTION KEY - ARC Audio Return Channel (ARC) is a feature that sends audio from the TV back down the HDMI cable to its source device, in this case, the switcher, Not all displays support ARC; check your Users Guide for additional information. ( Default = ARC Disabled ) The “Audio &...

  • Page 9: Front Panel- Aux

    FRONT PANEL- AUX FRONT PANEL 10. FUNCTION KEY - AUX (The audio additional on the “Audio / ARC” port ) The AUX FUNCTION feature allows you to replace the embedded HDMI audio signal with an audio signal that is connected to the switchers Audio AUX Input.

  • Page 10: Front Panel- Edid

    FRONT PANEL- EDID FRONT PANEL 12. FUNCTION KEY - EDID (1) Used to display change current EDID mode. - Press EDID to select new EDID mode or select - Press SOURCE row #1 or #2 Select EDID modes. - Press ENTER to ready memory location. - Or press EDID again to cancel operation.

  • Page 11: Front Panel - All - Off - Lock - Enter

    FRONT PANEL - ALL - OFF - LOCK - ENTER FRONT PANEL 13. FUNCTION KEY - ALL Disables (mute) video on all destinations OR assign the same source to all destinations. Option 1 - Press ALL followed by OFF button. The display will show ”0” to indicate none of the destinations are assigned a video source. Option 2 - Press ALL followed by Source 1 thru 8.

  • Page 12: Front Panel - Recall - Memory

    FRONT PANEL - RECALL - MEMORY FRONT PANEL 17. FUNCTION KEY - RECALL The system will show previously stored presets, up to a total of 16. Presets are stored in local memory using Source keys 1 thru 8 or Destination keys 1 thru 8 as the memory preset location. - Press RECALL button.

  • Page 13: Rear Panel

    BACK PANEL - SWITCH CONTROLS BACK PANEL 1. DC POWER INLET: Power Socket : The Switcher is fi tted with a DC power plug input connector. DC Jack - inner OD Ø 2.1mm (+ ) Ensure that the used is of an approved type and is of suffi cient Outside OD Ø...

  • Page 14: Back Panel - Hdmi Input / Output

    BACK PANEL - HDMI INPUT / OUTPUT BACK PANEL 5. INPUTS- 1,2,3,4,5,6,7, & 8 HDMI: HDMI Connector: HDMI Type A SMD 19pin Female Connect a HDMI signal source link of HDMI source direct HDMI socket connector. digital video/audio to this Female HDMI connector. This HDMI Note: With the proper adapters, the switcher port support HDMI and DVI digital video sources.

  • Page 15: Remote Control

    REMOTE CONTROL Before making any connections to the switcher, observe the following: • Ensure the mains voltage supply matches the label on the supplied plug- Pack (+/- 10%). • Ensure that the power switch is OFF. • Ensure that all system grounds (earth) are connected to a common point. •...
  • Page 16 REMOTE PROTOCOL COMMANDS IR REMOTE CUSTOM AND DATA CODES (NEC STANDARD) HOW TO SETUP IR CODES : CUSTOM CODE : 01FC POWER ON : 01FC A15E POWER OFF : 01FC A25D ARC : 01FC B847 LOCK : 01FC B54A AUX : 01FC 9966 EDID : 01FC B748...

  • Page 17: Edid Functions

    EDID FUNCTION EDID FUNCTION FOR HDMI MATRIX SWITCHER EDID Setup To Change the EDID Setup Step 1. Press the EDID button The display will show the currently selected EDID mode Step 2. Press SOURCE #1 or #2 button row The button will fl ash blue and the display will show the current Embedded EDID Status. Step 3.
  • Page 18 EDID FUNCTION Mode 5 . H36-3D-M (1080p-36 bits) Audio Support : MAT(MLP) 7.1CH, PCM 2CH, One Bit Audio 2CH, AC-3 5.1CH, DTS 5.1CH, PCM 7.1CH, Dolby Digital + 7.1CH, DTS-HD 7.1CH Mode 6 . 4K2K (24/30Hz) HDMI Support : 4K2K-3D, PCM 2CH (3860x2160-24/30Hz) Audio Support: PCM 2CH Mode 7 .
  • Page 19 EDID FUNCTION Learning EDID Single to Single Example : Learn Destination #8 EDID To Source #5. The button will fl ash blue and the display will show the current Embedded EDID Step 1. Press EDID button Status. Step 2. Press the Destination #8 button row Copy the Destination #8 Display EDID.
  • Page 20 EDID FUNCTION - PASS MODE The PASS feature is part of a fi rmware update released after JUNE 2014. If you do not see the PASS feature then you do not have the latest fi rmware. You should contact your place of purchase for availability of a fi rmware update. Note all devices are eligible for this fi...

  • Page 21: Typical Application

    TYPICAL APPLICATION INSTALLING DIAGRAM Samples connection : Using Switch IR External port, RS-232 or Ethernet command to control Switcher SB-5688AK via one PC or SB-100 IR receiver transmit the SB-5688AK’s IR signal. NOTE: 1. Switcher IR External port : Use SB-100 IR signal Receiver.
  • Page 22 TYPICAL APPLICATION INSTALLING DIAGRAM Samples connection : 1. Mixing Auxiliary Audio into HDMI source port via SPDIF port output to Audio Amplifi er. 2. Audio output link ARC from TV return channel via SPDIF port output to Audio Amplifi er. NOTE: 1.

  • Page 23: Ir Extender

    IR EXTENDER IR RECEIVER: 1. SB-100 IR 300M Receiver Device Cable (3C) IR Receiver (SB-100) R oHS /95/E C INP UT R S -232 IR E XT. in DC 12V IR Rx RS - 232 IR EXT . SB-100 SB-100 IR Receiver Set SB-100 Maximum Distance ~ 984 feet (300 meters) 2.

  • Page 24: Pin Configuration

    IR EXTENDER IR EMITTER: 1. SB-101 IR 300M Transmitter Device Cable (3C) IR Transmitter (SB-101) IR out CAT6/6a/7 DC 12V IR in R oHS /95/E C IR Tx From OUTPUT Receiver Receiver SB-101 SB-101 IR Transmitter Set SB-101 Maximum Distance ~ 984 feet (300 meters) 2.

  • Page 25: Ethernet Serial Interface

    ETHERNET SERIAL INTERFACE ETHERNET SERIAL INTERFACE CONNECT A PC OR CONTROL SYSTEM VERSION COMPATIBLE V2.0 For a complete list of commands, please reference external document extended Ethernet Protocol Instruction Manual. ETHERNET SERIAL INTERFACE Pin Ethernet Reference TXOP TX + TXON TX - RXIP RX +...

  • Page 26: Rs-232 Protocol

    RS-232 SERIAL INTERFACE RS-232 SERIAL INTERFACE CONNECT A PC OR CONTROL SYSTEM. VERSION COMPATIBLE V2.0 For a complete list of commands, please reference external document extended RS-232 Protocol Instruction Manual. RS-232 Confi guration RS-232 cable is a straight thru cable and not null-modem Defi...

  • Page 27: Limited Warranty

    Product. The Product is sold to you and any use of any associated intellectual property is deemed to be licensed to you by SHINYBOWUSA for your personal use only.
  • Page 28 M ULT IM EDI A AUDIO AN D V IS UA L 122 Rose Ln. Suite 303 | Frisco, Texas 75034 1-877-SHINY-USA 1-877-744-6987 1-972-377-2508 sales@shinybowusa.com www.shinybowusa.com...
