INSTRUCTION MANUAL
M ULT I MEDI A AU DIO A N D VI SU A L
MODEL : SB-5688LCM-A
8x8 HDMI Matrix Switch with Audio
HDMI Matrix Switcher
HDMI Matrix Switcher Series
Thank you for purchasing the SB-5688LCM-A HDMI Matrix Switcher. You will fi nd this unit easy to install and
highly reliable but it is essential that you read this manual thoroughly before attempting to use matrix switcher.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SB-5688LCM-A and is the answer not in the manual?

Questions and answers

Related Manuals for Shinybow USA SB-5688LCM-A

Summary of Contents for Shinybow USA SB-5688LCM-A

  • Page 1 HDMI Matrix Switcher Series Thank you for purchasing the SB-5688LCM-A HDMI Matrix Switcher. You will fi nd this unit easy to install and highly reliable but it is essential that you read this manual thoroughly before attempting to use matrix switcher.

  • Page 2: Safety Information

    SAFETY INFORMATION To ensure the best results from this product, please read this manual and all other documentation before operating your equipment. Retain all documentation for future reference. Follow all instructions printed on unit chassis for proper operation. To reduce the risk of fi re, do not spill water or other liquids into or on the unit, or operate the unit while standing in liquid. Make sure power outlets conform to the power requirements listed on the back of the unit.

  • Page 3: Table Of Contents

    We make no commitment to update or to keep current the information contained in this document. Two unique features of the SB-5688LCM-A is separate audio Inputs and Outputs. We reserve the right to make improvements to this document and/ or product at any time and without notice.

  • Page 4: Package Contents & Features

    When power is removed and resorted, the last confi guration will be invoked. PACKAGE CONTENTS Check that you have the following components; • SB-5688LCM-A Matrix Switcher • IR remote controller (SW-5688) • 19-inch ear mount bracket (Part # 1U-440 L) •...

  • Page 5: Specifications

    SPECIFICATIONS SPECIFICATIONS Type of HDMI Switcher: 8x HDMI inputs To 8x HDMI Outputs Matrix Switcher HDMI Support: HD 1080p-@60Hz, H36-bit Deep color, 3D (1.4a) formats HDCP / CEC Support: HDCP 2.0 Compliant, CEC Compliant Video Bandwidth: Double Data Rates: 340Mhz, Total 6.75Gbps bandwidth Digital Video Support: Full HD resolution : 480i / 480p / 720p / 1080i / 1080p Digital Audio Support: Multi Audio Formats 5.1 / 7.1, MAT(MLP) Dolby Digital, Dolby TrueHD, Dolby Digital Plus, DTS, DTS-ES 6CH, DTS-HD, DTS-HD-HRA, DTS-HD Master, (PCM-2CH)

  • Page 6: Front Panel

    FRONT PANEL FRONT PANEL 1. POWER SWITCH The power switch turns the unit on and off. The LCM will illuminate red to indicate that the switcher is ON and is receiving power. The Switcher will remember that last state during a power cycle. When power is removed and resorted, the last confi guration will be evoked. 2.
  • Page 7 FRONT PANEL FRONT PANEL 8. FUNCTION KEY - ALL Disables (mute) video on all destinations OR Selects the same source to all destinations. Option 1 - Press ALL followed by OFF button. The display will show “ 0 “ indicating all destinations have no video selected. Option 2 - Press ALL followed by Source 1 thru 8.
  • Page 8 FRONT PANEL FRONT PANEL 13. FUNCTION KEY - MEMORY The system will show store presets, up to a total of 16. Presets are stored in local memory using Source keys 1 thru 8 or Destination keys 1 thru 8 as the memory preset location. - Confi...

  • Page 9: Rear Panel

    REAR PANEL REAR PANEL Power Plug: 1. DC POWER INLET ᴓ DC Jack - inner OD 2.1mm (+ ) The Switcher is fi tted with a AC power plug input connector. Ensure ᴓ Outside OD 5.5mm (GND) that the used is of an approved type and is of suffi cient current Power input - 12VDC, 5A carrying connector capacity with the correct voltage and connector polarity.

  • Page 10: Typical Application

    TYPICAL APPLICATION INSTALLING DIAGRAM Sample connection using HDBaseT IR Transmitters (SB-6335T) and HDBaseT IR Receiver (SB-6335R) to control a projector for 100M long distance via category cable (CAT6/6a/7). NOTE: 1. IR Control Projector Over HDBaseT Extender: Use HDBaseT Transmitter (SB-6335T or SB-6320T) Use HDBaseT Receiver (SB-6335R or SB-6320R) 2.
  • Page 11 TYPICAL APPLICATION INSTALLING DIAGRAM Sample connection using DVI & Audio input and link to the AUDIO Amplifi er via SPDIF digital signal output. NOTE : 1. Use DVI and Audio Input via DVI Player Device. 2. HDMI display support DVI input via HDMI HDTV Support DVI input 3.

  • Page 12: Remote Control

    REMOTE CONTROL Before making any connections to the switcher. Observe the following: > Ensure the mains voltage supply matches the label on the > Connect all audio video sources and destination equipment supplied plug-pack (+/- 10%) > Power up all source and destination audio-visual sources >...
  • Page 13 REMOTE CONTROL IR REMOTE CUSTOM AND DATA CODES (NEC STANDARD) HOW TO SETUP IR CODES : CUSTOM CODE : 09F6 POWER ON : 09F6 A15E POWER OFF : 09F6 A25D ALL : 09F6 B04F OFF : 09F6 B14E EDID : 09F6 B748 LOCK : 09F6 B54A...

  • Page 14: Ir Extender

    IR EXTENDER IR RECEIVER: 1. SB-100 IR 300M Receiver Device Cable (3C) IR Receiver (SB-100) R oHS /95/E C INP UT R S -232 IR E XT. in DC 12V IR Rx RS - 232 IR EXT . SB-100 SB-100 IR Receiver Set SB-100 Maximum Distance ~ 984 feet (300 meters) 2.

  • Page 15: Pin Configuration

    IR EXTENDER IR EMITTER: 1. SB-101 IR 300M Transmitter Device Cable (3C) IR Transmitter (SB-101) IR out CAT6/6a/7 DC 12V IR in R oHS /95/E C IR Tx From OUTPUT Receiver Receiver SB-101 SB-101 IR Transmitter Set SB-101 Maximum Distance ~ 984 feet (300 meters) 2.

  • Page 16: Edid Function

    EDID FUNCTION EDID FUNCTION SETUP EDID setup To change the EDID setup Step 1. Press the EDID button The display will show the currently selected EDID mode Step 2. Press SOURCE #1 or #2 button row The button will fl ash blue and the display will show the current Embedded EDID Status.
  • Page 17 EDID FUNCTION NOTE : The already learned EDID cannot be modifi ed. You can only rebuild a new Learning EDID. For example: When the Source has “Learned” the EDID data from a destination, It will save that EDID information into EPROM and the EDID data cannot change.
  • Page 18 EDID FUNCTION EDID FUNCTION : LEARNING Learning EDID Single to Single Example : Learn Destination #8 EDID To Source #5. The button will fl ash blue and the display will show the current Embedded EDID Press the EDID button Step 1. Status.
  • Page 19 EDID FUNCTION Auto mode defi nition Common Resolution and Audio Switcher will fi nd highest common Resolution and Audio from all destination EDID to link Source. Example for single source Destination > press #1 and then Source > press #1 Destination device #1 will set to the highest common resolution and Audio of source #1 Example for multiple sources Destination device #1, #2, #3 will be set to the highest common resolution and Audio available and source device #1 will output...

  • Page 20: Ethernet Serial Interface

    ETHERNET SERIAL INTERFACE ETHERNET SERIAL INTERFACE CONNECT A PC OR CONTROL SYSTEM. VERSION COMPATIBLE V2.0 For a complete list of commands, please reference external document extended Ethernet Protocol Instruction Manual. ETHERNET SERIAL INTERFACE Pin Ethernet Reference TXOP TX + TXON TX - RXIP RX +...

  • Page 21: Rs-232 Serial Interface

    RS-232 SERIAL INTERFACE RS-232 SERIAL INTERFACE CONNECT A PC OR CONTROL SYSTEM. VERSION COMPATIBLE V2.0 For a complete list of commands, please reference external document extended RS-232 Protocol Instruction Manual. RS-232 SERIAL INTERFACE RS-232 Defi nition -------- Not used Transmitter Receiver -------- Not used...

  • Page 22: Limited Warranty

    LIMITED WARRANTY PLEASE READ THE FOLLOWING TERMS AND CONDITIONS CAREFULLY BEFORE USING THIS HARDWARE, COMPONENTS AND SOFTWARE PROVIDED BY, THROUGH OR UNDER SHINYBOWUSA, INC (COLLECTIVELY, THE “PRODUCT”). By using installing or using the Product, you unconditionally signify your agreement to these Terms and Conditions. If you do not agree to these Terms and Conditions, do not use the Product and return the Product to SHINYBOWUSA, Inc.
  • Page 23 M ULT I MEDI A AU DIO A N D VI SU A L 1399 Wildfi re Lane | Frisco, TX 75034 1-877-SHINY-USA 1-877-744-6987 1-972-377-2508 sales@shinybowusa.com www.shinybowusa.com...
