Technical specifications

Technical specifications
General
Description
Transmission Frequency
Transmission Power
Unobstructed Effective
Range
Spread Spectrum
Modulation Mode
Operating Temperature
Operating Humidity
Camera
Description
Image Sensor
Resolution
Minimum Illumination
Night Vision Distance
PIR Range
View Angle
Power Consumption (Max.) Max 460mA
Power Supply
Dimensions
Weight
LCD receiver
Description
Display
LCD Resolution
Receiving Sensitivity
Power Consumption (Max.) 7" Model: 950mA
Power Supply
Dimensions
Weight
54
2,400~2,483.5MHz
16dBm
650ft / 200m (line of sight)
FHSS
GFSK
14 ~ 122° Fahrenheit / -10 ~ +50° Celsius
< 85%
1/4" CMOS Image Sensor
640 x 480pxl (NTSC)
0Lux (IR on)
40ft (12m)
21ft (6.5m)
Diagonal 52°
9V DC
W: 75mm, L: 110mm, H: 190mm
0.60lbs / 0.27kg
9" diagonal or 7" diagonal (check package for display size)
800x480
-81dBm
9" Model: 1050mA
5V DC
7" Model: W: 42mm, L: 201mm, H: 150mm
9" Model: W: 42mm, L: 254mm, H: 202mm
7" Model: 1.55lbs / 0.70kg
9" Model: 1.00lbs / 0.44kg
