Camera overview
1
2
1
Microphone: Built-in microphone.
2
Lens: Camera lens.
3
PIR Sensor: Passive IR motion sensor.
4
Speaker: Speaker for intercom.
5
Night Vision IR: Night vision IR LEDs.
6
Pair: Pairing button. For more details, see "Pairing/adding cameras" on page 33.
7
Antenna: Wireless antenna.
8
Power Cable: Connect the included power adapter to the cable extending from the camera.
ATTENTION
This camera includes an Auto Mechanical IR Cut Filter. When the camera
changes between day mode and night vision mode, an audible clicking noise
may be heard coming from the camera. This clicking is normal, and indicates
that the camera filter is working.
5
4
3
6
7
Camera overview
8
5
