Recording
• Enable Auto Sequence Viewing mode: Press
motion is detected, the system will display and record the triggered camera on-screen. When
motion recording is over, Auto Sequence Viewing mode will continue as normal.
• Change channels manually: Press UP/DOWN to select a camera. The system will ONLY
record the selected camera; it will not record motion detected by other cameras.
• Enable Screen Saver mode: Press
detected, the system will display and record the triggered camera on-screen. When motion
recording is over, Screen Saver mode will continue as normal. For details on configuring
Screen Saver mode, see "Screen Saver (digital picture frame) mode" on page 28.
NOTE: By default, the system is set to record for 5 seconds after the triggered motion event.
For details on adjusting the motion recording time, see "Configuring motion
recording duration" on page 20 below.
3 Press again to stop motion recording. "MOTION" will turn off on the receiver.
Recording tip:
If you are using more than one camera, it is highly recommended to use Quad mode with
Motion Recording. Quad mode allows you to see all four cameras at once. You can set the
system to record the entire screen, so that video from up to 4 cameras is recorded (to
configure 4 channel recording, see "Selecting Single Channel or 4 Channel motion recording"
on page 21).

Configuring motion recording duration

Use the Duration menu to set the length of the time
the system will record after motion is detected by
a camera.
To change the motion recording time:
1 Press , then select Recording and press OK.
2 Select Motion Record and press OK.
3 Select Duration and press OK.
,
4 Select 5 seconds
press OK.
5 Press until all menus are closed.
20
15 Seconds, or 30 Seconds and
until a single channel is shown. When
to enable screen saver mode. When motion is
