Icom ID-RP1 Instruction Manual page 8

2
CONNECTIONS AND INSTALLATIONS
D D AH-1415 (1.2 GHz antenna)
• Mounting to a pole 1
Pole
1
(32–60 mm; 1 ⁄ –2
4
V-bolt
Pole clamp
Bracket
D D AH-1045/AH-1080
(10 GHz Offset-Parabola antenna)
Direction and angle adjustment is required for the AH-
1045/1080 installation. See the AH-1045/AH1080 in-
struction manual for both the installation and the
adjustment details.
6
AH-1415
" (d))
3
⁄
8
Nut
S-washer
to canceller unit
• Mounting to a pole 2
Pole clamp
V-bolt
Pole
(32–60 mm
" (d))
1 3
; 1 ⁄ –2 ⁄
4 8
Bracket
AH-1415
Nut
S-washer
to canceller unit
