BP7384 Camden, CF3600
3/12/09
12:37 PM
Page 1
READ AND SAVE THESE INSTRUCTIONS
CAMDEN
™
52" Damp Location

Ceiling Fan

Owner's Manual
Model Numbers
CF3600AP
CF3600ORH
Antique Pewter
Oil Rubbed Bronze
with Highlights
15.9
Net Weight:
Lbs.
Part No. F40BP73840000
Form No. BP7384
Model No.: CF3600

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CAMDEN CF3600AP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Emerson CAMDEN CF3600AP

Summary of Contents for Emerson CAMDEN CF3600AP

  • Page 1: Ceiling Fan

    BP7384 Camden, CF3600 3/12/09 12:37 PM Page 1 READ AND SAVE THESE INSTRUCTIONS CAMDEN ™ 52” Damp Location Ceiling Fan Owner's Manual Model Numbers CF3600AP CF3600ORH Antique Pewter Oil Rubbed Bronze with Highlights 15.9 Net Weight: Lbs. Part No. F40BP73840000 Form No.

  • Page 2: Safety Instructions

    WARNING: This product is designed to use only those parts supplied with this product and/or any accessories designated specifically for use with this product by Emerson Electric Co. Substitution of parts or accessories not designated for use with this product by Emerson Electric Co. could result in personal injury or property damage.
  • Page 3 2. One hairpin clip parts or accessories not designated for 3. Two #8-32 x 1-1/4” threaded studs use with this product by Emerson Electric 4. Two #8 external tooth lockwashers Co. could result in personal injury or 5. Two #8-32 knurled knobs property damage.
  • Page 4 BP7384 Camden, CF3600 3/12/09 12:37 PM Page 4 C. COUPLING A. FAN MOTOR B. MOTOR COVER ASSEMBLY COVER D. CEILING COVER E. SWITCH ADAPTER PLATE G. BLADE MEDALLION (4) F. BLADE FLANGE (4) J. HANGER BALL/ DOWNROD ASSEMBLY H. SWITCH COVER PLATE I.

  • Page 5: Electrical Requirements

    BP7384 Camden, CF3600 3/12/09 12:37 PM Page 5 Electrical Requirements WARNING To reduce the risk of personal injury, do Your new ceiling fan will require a not bend the blade flange when installing grounded electrical supply line of 120 volts the blade flanges, balancing the blades or AC, 60 Hz, 15 amp circuit.
  • Page 6 BP7384 Camden, CF3600 3/12/09 12:37 PM Page 6 6. Turn the switch adapter plate clockwise Note: Be sure the flange screws on the blade assembly are facing down for and tighten both screws (Figure 4). correct installation into the motor hub. Reinstall the other pan head screw in 3.
  • Page 7 BP7384 Camden, CF3600 3/12/09 12:37 PM Page 7 properly installed to prevent the clevis pin from working loose. Pull on the downrod to make sure the clevis pin is SWITCH COVER properly installed. ASSEMBLY 13. Install the 5/16-18 x 1/4” setscrew into the threaded hole on the motor SWITCH COVER SWITCH CHAIN...
  • Page 8 BP7384 Camden, CF3600 3/12/09 12:37 PM Page 8 17. Reinstall the hanger ball (Figure 10) on NOTE: Be careful not to scratch the the downrod as follows. Route the motor downrod with the ceiling cover during leads through the downrod. Position the installation.

  • Page 9: Your Ceiling Fan How To Hang

    BP7384 Camden, CF3600 3/12/09 12:37 PM Page 9 How to Hang WARNING Your Ceiling Fan Hanger bracket must seat firmly against outlet box. If the outlet box is recessed, remove wall board until bracket contacts WARNING box. If bracket and/or outlet box are not securely attached, the fan could wobble The fan must be hung with at least 7' of or fall.

  • Page 10: Your Ceiling Fan

    Emerson Electric Co. Substitution of parts or accessories not designated for threaded studs and installing the two use with this product by Emerson Electric knurled knobs (supplied). (Figure 15). Co. could result in personal injury or Tighten the knurled knobs securely property damage.
  • Page 11 Emerson Electric Co. Substitution of parts or accessories not designated for use with this product by Emerson Electric Co. could result in personal injury or property damage. Model No.: CF3600...

  • Page 12: Repair Parts

    BP7384 Camden, CF3600 3/12/09 12:37 PM Page 12 Repair Parts BLADE SETS SOLD SEPARATELY Before discarding packaging material, be certain all parts have been removed. HOW TO ORDER REPAIR PARTS WHEN ORDERING REPAIR PARTS, ALWAYS GIVE THE FOLLOWING INFORMATION: • PART NUMBER •...
  • Page 13 BP7384 Camden, CF3600 3/12/09 12:37 PM Page 13 Repair Parts Listing Part Numbers Model No. Model No. Description CF3600AP00 CF3600ORH00 Hanger Pack, Consisting of: 761655-80 761655-65 Hanger Bracket Assembly (1) — — Hanger Ball (1) — — Downrod (1) — —...

  • Page 14: Trouble Shooting

    BP7384 Camden, CF3600 3/12/09 12:37 PM Page 14 WARNING: FOR YOUR OWN SAFETY TURN OFF POWER AT FUSE BOX OR CIRCUIT BREAKER BEFORE TROUBLE SHOOTING YOUR FAN. Trouble Shooting TROUBLE PROBABLE CAUSE SUGGESTED REMEDY 1. Fuse or circuit breaker 1. Check main and branch 1.
  • Page 15 If repair of the motor or blades is not practical or possible within a reasonable time and no replacement can be provided, Emerson will refund the actual purchase price of your fan. WE WILL...
  • Page 16 BP7384 Camden, CF3600 3/12/09 12:37 PM Page 16 Air Comfort Products DIVISION OF EMERSON ELECTRIC CO. 8100 W. Florissant • St. Louis, MO 63136 Part No. F40BP73840000 Printed in China 03/09 Form No. BP7384 Model No.: CF3600...

This manual is also suitable for:
