READ AND SAVE THESE INSTRUCTIONS
CF3900WW01
CF3900PB01
CF3900HTW01 CF3900BS01
CF3900TG01
"APOLLO" Series
Ceiling Fan Owner's Manual
Part No. F40BP72340003
AMERICA'S FAN COMPANY
52" "APOLLO" Series
Model No.
CF3900AW01
CF3900WPB01
CF3900CK01
Net Weight:
CF3900AB01
CF3900OB01
CF3900BQ01
18.0
Lbs.
®
Form No. BP7234-3
Advertisement
Table of Contents
Related Manuals for Emerson APOLLO CF3900AB01
Summary of Contents for Emerson APOLLO CF3900AB01
- Page 1 READ AND SAVE THESE INSTRUCTIONS 52" “APOLLO” Series CF3900WW01 CF3900PB01 CF3900HTW01 CF3900BS01 CF3900TG01 “APOLLO” Series Ceiling Fan Owner's Manual Part No. F40BP72340003 AMERICA’S FAN COMPANY Model No. CF3900AW01 CF3900WPB01 CF3900CK01 18.0 Net Weight: Lbs. ® CF3900AB01 CF3900OB01 CF3900BQ01 Form No. BP7234-3...
- Page 2 You will be responsible for all insurance, freight or other transportation charges to our factory or authorized service center. Your Emerson Air Comfort Ceiling Fan should be properly packed to avoid damage in transit since we will not be responsible for any such damage.
-
Page 3: Safety Instructions
6. Follow the recommended instructions for the proper method of wiring your ceiling fan. If you do not know enough about electrical wiring, have your fan installed by a licensed electrician. WARNING: To avoid fire, shock or injury, do not use an Emerson or any other brand of control not specifically approved for this fan. -
Page 4: Tools Needed For Assembly
Emerson Company. Substitution of parts or acces- sories not designated for use with this product by Emerson Company could result in personal injury or property damage. 1. Open styrofoam unit containing fan. Remove top half of styrofoam unit. -
Page 5: Assembly Instructions
1. Remove the fan motor and housing assembly from styrofoam packaging and position it so that the top of the motor is facing you. 2. Separate, untwist and unkink the three motor leads. Route the motor leads through the hanger ball/downrod assembly and seat the downrod in the motor coupling. - Page 6 9. The fan comes with blue, black and white leads that are 80-inches long. Before installing fan, mea- sure up approximately 6 to 9-inches above the ball/downrod assembly. Cut off excess leads and strip back insulation 1/2-inch from end of leads.
-
Page 7: Electrical Requirements
Consult a qualified electrician if in doubt. If your fan is to replace an existing ceiling light fixture, turn electricity off at the main fuse box at this time and remove the existing light fixture. -
Page 8: How To Wire Your Ceiling Fan
(GROUND) FROM HANGER BALL Figure 4 NOTE: If you are using an Emerson Light Fixture with your fan, see Light Fixture Owner’s Manual for wiring. 2. Securely connect the fan motor white wire to the supply white (neutral) wire using wire connector supplied (Figure 4). -
Page 9: Attaching Light Kit
Emerson Company. Substitution of parts or acces- sories not designated for use with this product by Emerson Company could result in personal injury or property damage. -
Page 10: Repair Parts
Repair Parts Before discarding packaging material, be certain all parts have been removed. HOW TO ORDER REPAIR PARTS WHEN ORDERING REPAIR PARTS, ALWAYS GIVE THE FOLLOWING INFORMATION: • NAME OF ITEM • MODEL NUMBER • THE PART NUMBER • THE PART DESCRIPTION For repair parts, phone 1-800-654-3545. -
Page 12: Troubleshooting
3. Check to be sure screws which attach the fan blade flanges to the motor hub are tight. 4. Check to be sure the fan blade flanges seat firmly and uniformly to the surface of the motor hub. If flanges are...
