READ AND SAVE THESE INSTRUCTIONS
CF3000BS00
Brushed Steel
Part No. F40BP73490000
ORIGAMI
Damp Location

Ceiling Fan

Owner's Manual
Model Numbers
Net Weight:
CF3000ORB00
Oil Rubbed Bronze
25.0
Lbs.
Form No. BP7349
U.L. Model No.: CF3000

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CF3000BS00 ORIGAMI and is the answer not in the manual?

Questions and answers

Summary of Contents for Emerson CF3000BS00 ORIGAMI

  • Page 1: Ceiling Fan

    READ AND SAVE THESE INSTRUCTIONS ORIGAMI ™ Damp Location Ceiling Fan Owner's Manual Model Numbers CF3000ORB00 CF3000BS00 Oil Rubbed Bronze Brushed Steel 25.0 Net Weight: Lbs. Part No. F40BP73490000 Form No. BP7349 U.L. Model No.: CF3000...
  • Page 2: Safety Instructions

    WARNING: To reduce the risk of fire or electric shock, this fan should only be used with fan speed control SW105, manufactured by Rhine Electric Co., Ltd. WARNING: To avoid fire, shock or injury, do not use an Emerson or any other brand of control not specifically approved for this fan.
  • Page 3: Unpacking Instructions

    NOTE: Place the parts from the loose parts bags in a accessories not designated for use with this product small container to keep them from being lost. If any by Emerson Electric Co. could result in personal parts are missing, contact your local retailer or injury or property damage.
  • Page 4: How To Put Your Ceiling Fan Together

    How to Put Your Ceiling Fan Together 1. Remove the fan motor and housing assembly from 5. Install the setscrew (supplied) in the motor coupling the styrofoam packaging and position it so that the (Figure 2). While pulling up on the downrod, tighten top of the motor is facing you.
  • Page 5 12. Connect the switch housing blue wire single-pin WARNING connector to the black wire single-pin connector from the light kit assembly; connect the switch It is critical that the pin in the hanger ball is properly housing white wire single-pin connector to the installed and the setscrews securely tightened.
  • Page 6: Electrical Requirements

    1. Securely attach the hanger bracket to the outlet Electrical Requirements box using the two screws supplied with the outlet box. (Figure 10.) Your new ceiling fan will require a grounded electrical supply line of 120 volts AC, 60 Hz, 15 amp circuit. WARNING The outlet box must be securely anchored and capable of withstanding a load of at least 50 pounds.
  • Page 7: How To Wire Your Ceiling Fan

    How to Wire Your Ceiling Fan 3. Using wire connectors (supplied), make wiring con- If you feel that you do not have enough electrical nections as follows (Figure 12 and 13): wiring knowledge or experience, have your fan installed by a licensed electrician. a.
  • Page 8 SW105 RECEIVER BLACK SUPPLY 110V WIRE SUPPLY WHITE RECEIVER WIRE WHITE SUPPLY BLACK RECEIVER WIRE WIRE BLACK/WHITE BLUE RECEIVER WIRE RECEIVER WIRE BLUE FAN WIRE WHITE FAN WIRE YELLOW RECEIVER WIRE BLACK FAN WIRE DO NOT USE DOWNROD Figure 13 7.
  • Page 9: Light Kit Installation

    Switch Cover Installation Light Kit Installation If no light kit is desired, continue with switch 1. Screw the 75-watt (maximum) mini-candelabra (E11) base bulb (supplied) into the light kit socket cover installation. (Figure 16). Do not touch the glass bulb; use the 1.
  • Page 10 Ceiling Fan Procedures Installation of Wall Control General Your Emerson Ceiling Fan/Light Wall Control consists of a wall mount transmitter. The SW114 transmitter WARNING works in conjunction with the SW105 Receiver Turning off wall switch is not sufficient. To avoid (purchased separately).
  • Page 11: Operating Your Ceiling Fan

    Emerson Electric Co. Substitution of parts or accessories not designated for use with this product by Emerson Electric Co. could result in personal injury or property damage. U.L. Model No.: CF3000...
  • Page 12 INSTRUCTION TO THE USER (if device contains a digital device) This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interfer- ence in a residential installation.
  • Page 13: Troubleshooting

    WARNING: FOR YOUR OWN SAFETY TURN OFF POWER AT FUSE BOX OR CIRCUIT BREAKER BEFORE TROUBLE SHOOTING YOUR FAN. Trouble Shooting TROUBLE PROBABLE CAUSE SUGGESTED REMEDY 1. Fan will not start. 1. Fuse or circuit breaker blown. 1. Check main and branch circuit fuses or circuit breakers. 2.
  • Page 14: Repair Parts

    Repair Parts LIGHT FAN OFF U.L. Model No.: CF3000...
  • Page 15 Repair Parts Listing Part Numbers Model No. Model No. Description CF3000BS00 CF3000ORB00 Hanger Pack, Consisting of: 761655-27 761655-65 Hanger Bracket — — Hanger Ball — — Downrod - 6” — — Parts Bag Containing: 763439-1 763439 Pin, Clevis (1) — —...
  • Page 16 If repair of the motor or blades is not practical or possible within a reasonable time and no replacement can be provided, Emerson Electric Co. will refund the actual purchase price of your fan. We will ship the repaired product or replacement to you at no charge, but you are responsible for all costs or removal, reinstallation and shipping of the product to Emerson Electric Co.
