BP7514 CF320 Keane 12 2015_CF320 1/7/16 10:42 AM Page 1
READ AND SAVE THESE INSTRUCTIONS
52" Ceiling Fan Owner's Manual
CF320BS00 -
CF320SW00 -
Part No. F40BP75140000
Revision: 151218
KEANE
Model Numbers
Net Weight:
Questions, problems, missing parts: Before returning to the store call
Emerson Electric Customer Service
8 a.m. - 6 p.m., Eastern, Monday-Friday
1-800-654-3545
www.emersonfans.com
™
Brushed Steel
Satin White
13.5
Lbs.
4
3
2
1
0
• Español - página 23
• Français - page 45
Form No. BP7514
ETL Model No.: CF320
Advertisement
Table of Contents
Related Manuals for Emerson KEANE CF320BS00
Summary of Contents for Emerson KEANE CF320BS00
- Page 1 Satin White 13.5 Net Weight: Lbs. Questions, problems, missing parts: Before returning to the store call Emerson Electric Customer Service 8 a.m. - 6 p.m., Eastern, Monday-Friday • Español - página 23 1-800-654-3545 • Français - page 45 Part No. F40BP75140000 Form No.
-
Page 2: Table Of Contents
Electrical Codes. Use the National Electrical Code if specifically for use this product by Emerson Electric Co. Local Codes do not exist. The ceiling fan must be Substitution of parts or accessories not designated for... -
Page 3: Unpacking Instructions
Emerson Electric Switch Housing Adapter Co. Substitution of parts or accessories not designated for use with this product by Emerson Electric Co. could Switch Housing Cover result in personal injury or property damage. -
Page 4: Electrical Requirements
This Manual Is Designed to Make it as Easy as Possible for You to Assemble, Install, Operate and Maintain Your Ceiling Fan Tools Needed for Assembly Your Emerson Ceiling Fan comes supplied with a Fan Wall Control. This system allows you to regulate your ceiling fan One Phillips head screwdriver One stepladder speed. -
Page 5: Ceiling Fan Assembly
BP7514 CF320 Keane 12 2015_CF320 1/7/16 10:42 AM Page 5 3. Ceiling Fan Assembly GREEN GROUND WIRE Remove the hanger ball by loosening the Phillips head set screw in the hanger ball until the ball falls freely down the downrod (Figure 1). Remove the pin from the downrod, then remove the 4.5"... - Page 6 BP7514 CF320 Keane 12 2015_CF320 1/7/16 10:42 AM Page 6 3. Ceiling Fan Assembly (Continued) Align the clevis pin holes in the downrod with the holes in HAIRPIN the motor coupler. CLIP CLEVIS Install the clevis pin and secure with the hairpin clip (Figure 4).
- Page 7 BP7514 CF320 Keane 12 2015_CF320 1/7/16 10:42 AM Page 7 3. Ceiling Fan Assembly (Continued) Route the two motor leads through the hanger ball (Figure HANGER BALL 4.5" DOWNROD Reinstall the hanger ball on the downrod as follows: PHILLIPS HEAD Position the pin through the two holes in the downrod and SET SCREW align the hanger ball so the pin is captured in the groove in...
- Page 8 BP7514 CF320 Keane 12 2015_CF320 1/7/16 10:43 AM Page 8 3. Ceiling Fan Assembly (Continued) PARTIALLY ASSEMBLED CEILING FAN Turn the partially assembled ceiling fan upside down, place REMOVE & DISCARD the ceiling fan onto the two carton styrofoam pieces, in SHIPPING SPACERS &...
-
Page 9: How To Hang Your Ceiling Fan
BP7514 CF320 Keane 12 2015_CF320 1/7/16 10:43 AM Page 9 4. How to Hang Your Ceiling Fan CEILING WARNING The fan must be hung with at least 7' of clearance from floor to blades (Figure 12). LEAST FLOOR Figure 12 WARNING The outlet box and joist must be securely mounted and capable of supporting at least 50 lbs. - Page 10 BP7514 CF320 Keane 12 2015_CF320 1/7/16 10:43 AM Page 10 4. How to Hang Your Ceiling Fan (Continued) NOTE: CEILING COVER, SUPPL Y WIRES AND FAN WIRES OMITTED FOR CLARITY. Carefully lift the fan and seat the hanger ball/ downrod assembly on the hanger bracket that was just attached to the outlet box (Figure 14).
-
Page 11: Final Assembly
BP7514 CF320 Keane 12 2015_CF320 1/7/16 10:43 AM Page 11 5. Final Assembly Remove one #6-32 x 0.312” flat head screw from the motor hub and retain for later use. Loosen the other two #6-32 x 0.312” flat head screws on the MOTOR HUB motor hub for the installation of the switch housing adapter. -
Page 12: How To Wire Your Ceiling Fan
Emerson Electric Co. Substitution of parts or accessories not designated for use with this product by Emerson Electric Co. could result in personal injury or property damage. Securely connect the fan motor white wire to the supply... - Page 13 BP7514 CF320 Keane 12 2015_CF320 1/7/16 10:43 AM Page 13 6. How to Wire Your Ceiling Fan (Continued) Securely connect the fan motor black wire to the supply black (hot) wire using wire connector (supplied) (Figure 20). SUPPLY BLACK (HOT) LISTED WIRE CONNECTOR FAN MOTOR...
- Page 14 BP7514 CF320 Keane 12 2015_CF320 1/7/16 10:43 AM Page 14 6. How to Wire Your Ceiling Fan (Continued) Screw the two threaded studs (supplied) into the tapped holes in the hanger bracket (Figure 22). THREADED STUDS (2) Figure 22 Lift the ceiling cover up to the threaded studs and turn until studs protrude through the holes in the ceiling cover CEILING COVER (Figure 23).
-
Page 15: Installing The Wall Control
BP7514 CF320 Keane 12 2015_CF320 1/7/16 10:43 AM Page 15 7. Installing the Wall Control WARNING Turning off wall switch is not sufficient. To avoid possible electrical shock, be sure electricity is turned off at the main fuse box before wiring. All wiring must be in accordance with National and Local codes and the ceiling fan must be properly grounded as a precaution against possible electrical shock. -
Page 16: Using Your Ceiling Fan
BP7514 CF320 Keane 12 2015_CF320 1/7/16 10:43 AM Page 16 7. Installing the Wall Control (Continued) WALL OUTLET BOX Attach the SW46W Fan Control to the wall outlet box with SW46 FAN CONTROL two 6-32 x 3/4” screws (provided with control). Position the faceplate (provided with control) onto the speed control. -
Page 17: Maintenance
· Downrod Extension Kits specifically for use with this product by Emerson Electric Co. Substitution of parts or accessories not designated for use with this product by Emerson Electric Co. could result in personal injury or property damage. WARNING The use of any other control not specifically approved for this fan could result in fire, shock and personal injury. -
Page 18: Repair Parts
BP7514 CF320 Keane 12 2015_CF320 1/7/16 10:43 AM Page 18 11. Repair Parts PARTS BAG ETL Model No.: CF320... -
Page 19: Repair Parts
BP7514 CF320 Keane 12 2015_CF320 1/7/16 10:43 AM Page 19 11. Repair Parts Listing Model Numbers Description CF320BS00 CF320SW00 Hanger Ball Assembly, 761655-17 761655-92 Consisting of: Hanger Bracket — — Hanger Ball — — 4.5” Downrod — — Parts Bag Containing: 764769-CRM 764769-SW Wire Connectors (5) -
Page 20: Energy Efficient Use Of Ceiling Fans
- additional 2.75 m above the floor for optimal airflow. Consult your energy and dollar savings could be realized with this Emerson Retailer for optional mounting accessories. simple step! Using the Ceiling Fan Year Round. In the summer, use Turn Off When Not in the Room. -
Page 21: Ceiling Fan Limited Warranty
