Emerson AMHURST CF880BS00 Owner's Manual

54" ceiling fan
Hide thumbs

Advertisement

Quick Links

READ AND SAVE THESE INSTRUCTIONS
5 5 4 4 " " C C e e i i l l i i n n g g F F a a n n O O w w n n e e r r ' ' s s M M a a n n u u a a l l
CF880BS00 -
CF880VNB00 -
CF880VS00 -
Questions, problems, missing parts: Before returning to the store call
Part No. F40BP74720000
Revision: 130701
AMHURST
Model Numbers
Brushed Steel
Venetian Bronze
Vintage Steel
25.6
Net Weight:
Emerson Electric Customer Service
8 a.m. - 6 p.m., EST, Monday-Friday
1-800-654-3545
www.emersonfans.com
Lbs.
Form No. BP7472
ETL Model No.: CF880

Advertisement

loading

  Also See for Emerson AMHURST CF880BS00

  Related Manuals for Emerson AMHURST CF880BS00

  Summary of Contents for Emerson AMHURST CF880BS00

  • Page 1 Venetian Bronze CF880VS00 - Vintage Steel 25.6 Net Weight: Lbs. Questions, problems, missing parts: Before returning to the store call Emerson Electric Customer Service 8 a.m. - 6 p.m., EST, Monday-Friday 1-800-654-3545 Part No. F40BP74720000 Form No. BP7472 www.emersonfans.com Revision: 130701...
  • Page 2: Safety Instructions

    Emerson Electric Co. Substitution of parts or accessories not Additional Safety Instructions for Installation designated for use with this product by Emerson could result in personal injury or property damage. 1. To avoid possible shock, be sure electricity is turned...
  • Page 3: Unpacking Instructions

    Emerson Electric Co. Substitution of parts or Light Kit Adapter accessories not designated for use with this product Light Kit Assembly by Emerson Electric Co. could result in personal injury or property damage. Glass Bowl 60-Watt (max.) Candelabra Bulbs 1. Check to see that you have received the following...
  • Page 4: Ceiling Fan Assembly

    This Manual Is Designed to Make it as Easy as Possible for You to Assemble, Install, Operate and Maintain Your Ceiling Fan Installed Wire Length Wire Size A.W.G. Tools Needed for Assembly Up to 50 ft. One Phillips head screwdriver 50-100 ft.
  • Page 5 Ceiling Fan Assembly (continued) 5. Make sure the grommet is properly installed in the coupler cover, then slide the coupler cover on the CEILING downrod until it rests on the motor housing. Place the COVER ceiling cover over the downrod. Be sure that the HANGER BALL ceiling cover and the coupler cover are both oriented...
  • Page 6 Ceiling Fan Assembly (continued) 13. Remove one of the screws from the motor housing. MOTOR HOUSING Retain for future installation. Loosen the two SCREW (3) LIGHT KIT ADAPTER remaining screws in the motor housing for installation of the light kit adapter. KEY HOLE SLOT (2) 14.
  • Page 7: Electrical Requirements

    8 - 9 feet above the floor for optimal occupied space. Remember to adjust your thermostat airflow. Consult your Emerson Retailer for optional when using your ceiling fan - additional energy and mounting accessories.
  • Page 8: How To Hang Your Ceiling Fan

    How to Hang Your Ceiling Fan CEILING WARNING The fan must be hung with at least 7' of clearance from floor to blades (Figure 9). AT LEAST WARNING The outlet box and joist must be securely mounted and capable of supporting at least 50 lbs. Use only a U.L. outlet box listed as “Acceptable for Fan Support of 22.7 kg.
  • Page 9: How To Wire Your Ceiling Fan

    How to Wire Your Ceiling Fan If you feel that you do not have enough electrical wiring knowledge or experience, have your fan SUPPLY WHITE RECEIVER WHITE WIRE WIRE (NEUTRAL) installed by a licensed electrician. RECEIVER BLACK WIRE SUPPLY BLACK WARNING WIRE (HOT) RECEIVER...
  • Page 10: Installation Of Glass Shade

    Installation of Glass Shade 1. Install two 60-watt (maximum) candelabra base light bulbs (included) into the light fitter sockets (Figure 14). WARNING Over lamping the fan will result in the light bulbs being automatically shut off. Use only 60-watt maximum candelabra light bulbs.
  • Page 11: Using Your Ceiling Fan

    Using Your Ceiling Fan WARNING To avoid possible fire or shock, make sure that the electrical wires are completely inside the outlet box and not pinched between the ceiling cover and the ceiling. CEILING COVER THREADED 1. Push the wires and connectors up into the outlet box STUDS (2) while inserting the receiver fully into the hanger LOCKWASHERS (2)
  • Page 12 Figure 21 to stop turning, then slide the reverse switch to the “right” position, and turn fan on again (Figure 21). Please call Emerson technical support 19. The fan blades will turn in the opposite direction and reverse the airflow.
  • Page 13: Maintenance

    Emerson Electric Co. Substitution of parts or accessories not designated for use with this product The use of any other control not specifically approved by Emerson Electric Co. could result in personal injury for this fan could result in fire, shock and personal or property damage.
  • Page 14: Troubleshooting

    Trouble Shooting WARNING: FOR YOUR OWN SAFETY TURN OFF POWER AT FUSE BOX OR CIRCUIT BREAKER BEFORE TROUBLE SHOOTING YOUR FAN. TROUBLE PROBABLE CAUSE SUGGESTED REMEDY 1. Fuse or circuit breaker blown. 1. Check main and branch circuit fuses or circuit breakers. 1.
  • Page 15 Notes emersonfans.com Please contact 1-800-654-3545 for further assistance ETL Model No.: CF880...
  • Page 16: Repair Parts

    Repair Parts ..ETL Model No.: CF880...
  • Page 17 Repair Parts Listing Model Numbers Description CF880BS00 CF880VNB00 CF880VS00 Hanger Ball Assembly, 761655-17 761655-89 761655-93 Consisting of: Hanger Bracket — — — Hanger Ball — — — Downrod — — — Parts Bag Containing: 764397-1 764397 764397 Wire Connector (3) —...
  • Page 18 Notes ETL Model No.: CF880...
  • Page 19 What We Will Do To Correct Problems: If during the one (1) year warranty period the motor or any component or accessory of your Emerson Ceiling Fan is defective in materials or workmanship, or if during the expected lifetime of the Emerson Ceiling Fan (when used in accordance with the User Manual or other instructions) the motor is defective in materials or workmanship, you must contact Emerson during the applicable warranty period.
  • Page 20 Air Comfort Products DIVISION OF EMERSON ELECTRIC CO. 8100 W. Florissant • St. Louis, MO 63136 Questions, problems, missing parts: Before returning to the store call Emerson Electric Customer Service 8 a.m. - 6 p.m., EST, Monday-Friday 1-800-654-3545 www.emersonfans.com Retain this manual for future use.
