BP7522 Ideal CF330 02152017.qxp_CF330 2/15/17 11:44 AM Page 1
READ AND SAVE THESE INSTRUCTIONS
54" Ceiling Fan Owner's Manual
CF330BQ00 -
CF330GRT00 -
CF330SW00 -
Part No. F40BP75220000
Revision: 170215
IDEAL
Model Numbers
Net Weight:
Questions, problems, missing parts: Before returning to the store call
Emerson Electric Customer Service - 8 a.m. - 6 p.m., Eastern, Monday-Friday
www.emersonfans.com
™
Barbeque Black
Graphite
Satin White
15.8
Lbs.
1-800-654-3545
• Español - página 29
• Français - page 57
Form No. BP7522
ETL Model No.: CF330

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CF330 and is the answer not in the manual?

Questions and answers

Related Manuals for Emerson CF330

Summary of Contents for Emerson CF330

  • Page 1 15.8 Net Weight: Lbs. Questions, problems, missing parts: Before returning to the store call Emerson Electric Customer Service - 8 a.m. - 6 p.m., Eastern, Monday-Friday • Español - página 29 • Français - page 57 1-800-654-3545 Part No. F40BP75220000 Form No.

  • Page 2: Table Of Contents

    BP7522 Ideal CF330 02152017.qxp_CF330 2/15/17 11:44 AM Page 2 Table of Contents Section Page Section Page Safety Instructions ........2 9.

  • Page 3: Unpacking Instructions

    BP7522 Ideal CF330 02152017.qxp_CF330 2/15/17 11:44 AM Page 3 1. Unpacking Instructions WARNING Do not install or use fan if any part is damaged or missing. Call Toll-Free: 1-800-654-3545 PACKAGE CONTENTS WARNING Fan Motor Assembly Part Description Quantity Hanger Bracket...

  • Page 4: Electrical Requirements

    BP7522 Ideal CF330 02152017.qxp_CF330 2/15/17 11:44 AM Page 4 1. Unpacking Instructions (Continued) This Manual Is Designed to Make it as Easy as Possible for You to Assemble, Install, Operate and Maintain Your Ceiling Fan Tools Needed for Assembly Your Emerson Ceiling Fan comes supplied with a DC Receiver and Fan Wall Control.

  • Page 5: Ceiling Fan Assembly

    BP7522 Ideal CF330 02152017.qxp_CF330 2/15/17 11:44 AM Page 5 3. Ceiling Fan Assembly Flip the upper foam pad over and place on a stable SHIPPING working surface. MOTOR HUB RETAINERS (3) Remove the fan motor assembly from the protective plastic bag.
  • Page 6 BP7522 Ideal CF330 02152017.qxp_CF330 2/15/17 11:44 AM Page 6 3. Ceiling Fan Assembly (Continued) NOTE: Take care not to scratch the fan housing 1/4-20 x 1/2" OVAL HEAD SCREWS when installing the blade assemblies. (2 per assembly) Attach the Blade Flange Assembly onto the Fan Motor/ BLADE FLANGE ASSEMBLY Hub by tightening the 1/4-20 x 1/2”...
  • Page 7 BP7522 Ideal CF330 02152017.qxp_CF330 2/15/17 11:44 AM Page 7 3. Ceiling Fan Assembly (Continued) Remove the Hanger Ball by loosening the Phillips Head GREEN GROUND WIRE Set Screw in the Hanger Ball until the Ball falls freely down the 4.5” Downrod (Figure 5).
  • Page 8 BP7522 Ideal CF330 02152017.qxp_CF330 2/15/17 11:44 AM Page 8 3. Ceiling Fan Assembly (Continued) Align the Clevis Pin holes in the Downrod with the holes in the Motor Coupler. Install the Clevis Pin and secure with the Hairpin Clip (Figure 8).
  • Page 9 BP7522 Ideal CF330 02152017.qxp_CF330 2/15/17 11:44 AM Page 9 3. Ceiling Fan Assembly (Continued) 3.11 Route the two 80” Motor Wires through the Hanger Ball (Figure 11). HANGER BALL Reinstall the Hanger Ball on the Downrod as follows: DOWNROD Position the Pin through the two holes in the Downrod...

  • Page 10: How To Hang Your Ceiling Fan

    BP7522 Ideal CF330 02152017.qxp_CF330 2/15/17 11:44 AM Page 10 4. How to Hang Your Ceiling Fan WARNING CEILING The fan must be hung with at least 7' of clearance from floor to blades (Figure 13). WARNING To avoid possible electrical shock, be sure electricity is turned off at the main fuse box before wiring.
  • Page 11 BP7522 Ideal CF330 02152017.qxp_CF330 2/15/17 11:44 AM Page 11 4. How to Hang Your Ceiling Fan (Continued) WARNING The outlet box and joist must be securely mounted and capable of supporting at least 50 lbs. Use only a U.L. outlet box listed as “Acceptable for Fan Support of 22.7 kg.

  • Page 12: How To Wire Your Ceiling Fan

    BP7522 Ideal CF330 02152017.qxp_CF330 2/15/17 11:44 AM Page 12 5. How to Wire Your Ceiling Fan If you feel that you do not have enough electrical wiring knowledge or experience, have your fan installed by a licensed electrician. WARNING GROUND...
  • Page 13 BP7522 Ideal CF330 02152017.qxp_CF330 2/15/17 11:44 AM Page 13 5. How to Wire Your Ceiling Fan (Continued) Securely connect the Fan Motor White Wire to the Supply White (neutral) Wire using Wire Connector SUPPLY WHITE (supplied) (Figure 17). (NEUTRAL) LISTED WIRE...

  • Page 14: Final Assembly

    BP7522 Ideal CF330 02152017.qxp_CF330 2/15/17 11:44 AM Page 14 6. Final Assembly Engage the Fan Motor 2-Pin Wire Connector into the 2-pin Wire Connector of the LED Array (Figure 20). The connection is complete when you hear a soft click.
  • Page 15 BP7522 Ideal CF330 02152017.qxp_CF330 2/15/17 11:44 AM Page 15 6. Final Assembly (Continued) Screw the two Threaded Studs (supplied) into the tapped holes in the Hanger Bracket (Figure 23). HANGER BRACKET HOLES (2) THREADED STUDS (2) Figure 23 Lift the Ceiling Cover up to the Threaded Studs and...

  • Page 16: Wall Control Installation

    BP7522 Ideal CF330 02152017.qxp_CF330 2/15/17 11:44 AM Page 16 7. Wall Control Installation Preset Memory Feature: Your Emerson receiver is Your Emerson Ceiling Fan/Light Control consists of wall equipped with a preset memory feature. If the AC mounted transmitter and a receiver located inside the supply to the receiver is powered OFF through a wall motor assembly.
  • Page 17 BP7522 Ideal CF330 02152017.qxp_CF330 2/15/17 11:44 AM Page 17 7. Wall Control Installation (Continued) This control is designed to operate only one ceiling fan NOTE: Electric connections should be in accordance with the National Electrical Codes and all Local Codes. Before starting, disconnect power to the circuit at the fuse box or circuit breaker panel.
  • Page 18 BP7522 Ideal CF330 02152017.qxp_CF330 2/15/17 11:44 AM Page 18 7. Wall Control Installation (Continued) SINGLE-POLE INSTALLATION WARNING (One fan controlled by one wall control) Turning off wall switch is not sufficient. To avoid (See Figure 28). possible electrical shock, be sure electricity is turned off at the main fuse or circuit breaker box before wiring.
  • Page 19 BP7522 Ideal CF330 02152017.qxp_CF330 2/15/17 11:44 AM Page 19 7. Wall Control Installation (Continued) 3-WAY INSTALLATION (One fan controlled by two different wall controls) (See Figures 29 and 30). SECONDWALL FAN/LIGHT CONTROL WALL PURCHASE CONTROL SEPARATELY WARNING GROUND Turning off wall switch is not sufficient. To avoid...
  • Page 20 BP7522 Ideal CF330 02152017.qxp_CF330 2/15/17 11:44 AM Page 20 7. Wall Control Installation (Continued) 3-WAY WIRING DIAGRAM: WARNING NOTE: Retrofit 3-way installations are likely to include two traveler wires between the two wall Check to see that all connections are tight and that no boxes.

  • Page 21: Programming The Receiver Operating Frequency & High Speed Conditioning Of Fan Control

    BP7522 Ideal CF330 02152017.qxp_CF330 2/15/17 11:44 AM Page 21 8. Programming the Receiver Operating Frequency & High Speed Conditioning of Fan Control -- Important - Read This Section Carefully and Follow the High Speed Conditioning Instructions Closely -- PROGRAMMING THE RECEIVER OPERATING FREQUENCY &...

  • Page 22: Using Your Ceiling Fan

    BP7522 Ideal CF330 02152017.qxp_CF330 2/15/17 11:44 AM Page 22 9. Using Your Ceiling Fan WARNING Fan installation must be completed, including the installation of the fan blades, before testing the wall POWER control. INDICATOR LIGHT Your Wall Control has full control of your Fan and Light...

  • Page 23: Maintenance

    BP7522 Ideal CF330 02152017.qxp_CF330 2/15/17 11:44 AM Page 23 10. Maintenance IMPORTANT CARE INSTRUCTIONS WARNING for your Ceiling Fan Do not use water when cleaning your ceiling fan. Periodic cleaning of your new ceiling fan is the only It could damage the motor or the blades and create the maintenance that is needed.

  • Page 24: Repair Parts

    BP7522 Ideal CF330 02152017.qxp_CF330 2/15/17 11:44 AM Page 24 12. Repair Parts HARDWARE BAG ETL Model No.: CF330...

  • Page 25: How To Order Repair Parts

    BP7522 Ideal CF330 02152017.qxp_CF330 2/15/17 11:44 AM Page 25 12. Repair Parts Listing Model Numbers Description CF330BQ00 CF330GRT00 CF330SW00 Hanger Ball Assembly, 761655-19 761655-102 761655-92 Consisting of: Hanger Bracket (1) — — — Hanger Ball (1) — — — 4.5” Downrod (1) —...

  • Page 26: Troubleshooting

    BP7522 Ideal CF330 02152017.qxp_CF330 2/15/17 11:44 AM Page 26 13. Troubleshooting WARNING FOR YOUR OWN SAFETY TURN OFF POWER AT FUSE BOX OR CIRCUIT BREAKER BEFORE TROUBLESHOOTING YOUR FAN. TROUBLE PROBABLE CAUSE SUGGESTED REMEDY 1. Fan will not start. 1. Loose electrical connections in the 1.

  • Page 27: Ceiling Fan Limited Warranty

    This limited warranty will cover the Emerson Ceiling Fan motor for the expected lifetime of your Emerson Ceiling Fan (when operated in accordance with your Owner's Manual or other instructions provided by Emerson to you with the Emerson Ceiling Fan). LED drivers are covered for a period of three (3) years, and any LED array is covered for a period of five (5) years.
  • Page 28 BP7522 Ideal CF330 02152017.qxp_CF330 2/15/17 11:44 AM Page 28 SERIAL NUMBER: DATE CODE: The serial number of this fan can be found on the nameplate on top of the fan housing. The date code can be found on the carton and on top of the fan housing, stamped in ink on a white label. You should record this data above and keep it in a safe place for future use.
