BP7386, CF3400 Corsair
READ AND SAVE THESE INSTRUCTIONS
44" or 52" Ceiling Fan
Owner's Manual
CF3400AP
Antique Pewter
Part No. F40BP73860000
11/25/09
6:20 AM
Page 1
CORSAIR
Model Numbers
CF3400ORH
Oil Rubbed Bronze
with Highlights
24" - 21.4
36" - 22.9
Net Weight:
48" - 24.5
™
Lbs.
Form No. BP7386
Model No.: CF3400
Advertisement
Table of Contents
Related Manuals for Emerson CORSAIR 44"
Summary of Contents for Emerson CORSAIR 44"
- Page 1 BP7386, CF3400 Corsair 11/25/09 6:20 AM Page 1 READ AND SAVE THESE INSTRUCTIONS CORSAIR ™ 44” or 52” Ceiling Fan Owner's Manual Model Numbers CF3400ORH CF3400AP Oil Rubbed Bronze Antique Pewter with Highlights 24” - 21.4 36” - 22.9 Net Weight: Lbs.
-
Page 2: Safety Instructions
WARNING: This product is designed to use only those parts supplied with this product and/or any accessories designated specifically for use with this product by Emerson Electric Co. Substitution of parts or accessories not designated for use with this product by Emerson Electric Co. could result in personal injury or property damage. -
Page 3: Unpacking Instructions
Emerson Electric Co. Substitution of parts or accessories not designated for A. CEILING FAN use with this product by Emerson Electric ASSEMBLY Co. could result in personal injury or property damage. 1. Open carton containing fan. Remove B. -
Page 4: Electrical Requirements
BP7386, CF3400 Corsair 11/25/09 6:20 AM Page 4 Electrical Requirements How to Hang Your Ceiling Fan Your new ceiling fan will require a grounded electrical supply line of 120 volts WARNING AC, 60 Hz, 15 amp circuit. Turning off wall switch is not sufficient. The outlet box must be securely anchored To avoid possible electrical shock, be and capable of withstanding a load of at... -
Page 5: How To Wire Your Ceiling Fan
Emerson Electric 3. Pull the electrical supply wires through Co. could result in personal injury or the opening on the back side of the property damage. -
Page 6: Blade Installation
BP7386, CF3400 Corsair 11/25/09 6:20 AM Page 6 2. Securely connect the fan motor white 6. Carefully slide the motor ring up the wire to the supply white (neutral) wire motor housing and position the ring so using wire connector supplied that the reverse switch slot in the ring is (Figure 4). - Page 7 BP7386, CF3400 Corsair 11/25/09 6:20 AM Page 7 1. Remove the wall plate and screws from the existing wall switch. Pull switch out BLADE MEDALLION from wall outlet box. #10-32 x .75" 2. Disconnect wire from existing fan wall OVAL HEAD switch (Figure 7).
-
Page 8: Using Your Ceiling Fan
BP7386, CF3400 Corsair 11/25/09 6:20 AM Page 8 Using Your Ceiling Fan TO NEUTRAL TO FAN MOTOR LOAD BLACK BLACK Figure 10 IMPORTANT Fan installation must be completed, TO 120VAC SOURCE including the installation of the fan blades, before testing of the controls. Figure 8 1. -
Page 9: Troubleshooting
Do not use water when cleaning your parts or accessories not designated for ceiling fan. It could damage the motor or use with this product by Emerson Electric the blades and create the possibility of an Co. could result in personal injury or electrical shock. - Page 10 BP7386, CF3400 Corsair 11/25/09 6:20 AM Page 10 Repair Parts Listing Part Numbers Model No. Model No. Description CF3400AP00 CF3400ORH00 Ceiling Plate (1) 763816-AP 763816-ORH Hanger Bracket Assembly (1) 760732 760732 Hangerball Assembly (1) 763949 763949 Reverse Switch (1) 763898 763898 Axillary Capacitor 8.0 uF (1) 763948...
-
Page 11: How To Order Repair Parts
BP7386, CF3400 Corsair 11/25/09 6:20 AM Page 11 Repair Parts Before discarding packaging material, be certain all parts have been removed. HOW TO ORDER REPAIR PARTS WHEN ORDERING REPAIR PARTS, ALWAYS GIVE THE FOLLOWING INFORMATION: • PART NUMBER • PART DESCRIPTION •... -
Page 12: Limited Warranty
You will be responsible for all insurance, freight or other transportation charges to our factory or authorized service center. Your Emerson Air Comfort Ceiling Fan should be properly packed to avoid damage in transit since we will not be responsible for any such damage. -
Page 13: Installation Instructions
READ AND SAVE THESE INSTRUCTIONS Installation Instruction on New CSA Hanging Device INSTALLATION INSTRUCTIONS Always properly install the ceiling fan mounting plate to a structural ceiling joist that is capable of reliably supporting at least 50 pounds. PRELIMINARY PROCEDURES FOR EXTRA SUPPORT HANGING SYSTEM 2. - Page 14 8. To complete fan assembly, proceed to “How to Wire Your Ceiling Fan” in the Ceiling Fan Instructions Manual. Figure 4 Air Comfort Products DIVISION OF EMERSON ELECTRIC CO. Form No. BP7410 8100 W. Florissant • St. Louis, MO 63136 Part No. F40BP74100000...
